Processor
Processor family: Intel® Celeron®
On-board graphics card model: Intel® UHD Graphics
CPU configuration (max): 1
Processor boost frequency: 2.9 GHz
Processor frequency: 2 GHz
Processor cores: 4
Processor threads: 4
Processor model: N5105
Processor manufacturer: Intel
Memory
Flash memory: 8000 MB
Memory slots: 2
Maximum RAM supported: 16 GB
Internal memory type: DDR4
Internal memory: 8 GB
Memory form factor: SO-DIMM
Design
Number of fans: 1 fan(s)
Chassis type: Desktop
Display type: LCD
Fan diameter: 12 cm
Built-in display: Yes
Product colour: Black
Cooling type: Active
Power
Power consumption (sleep): 0.81 W
Power supply location: External
Power consumption (HDD standby): 27.7 W
Power supply unit (PSU) capacity: 250 W
AC input voltage: 100 - 240 V
Power consumption (typical): 48.5 W
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 230 mm
Height: 185.5 mm
Weight: 4.4 kg
Width: 233 mm
Network
Jumbo frames support: Yes
Ethernet LAN: Yes
Ethernet LAN data rates: 2500, 1000 Mbit/s, 100
Wake-on-LAN ready: Yes
Performance
Browser supported: Firefox, Chrome, Safari, Microsoft Edge
Backup features: USB drive, Cloud, iSCSI LUN
Backup function: Yes
Device class: Home & Home Office
Type: NAS
Noise level: 18.1 dB
Processor special features
Idle States: Yes
Intel 64: Yes
Enhanced Intel SpeedStep Technology: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel Trusted Execution Technology: No
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Software
Server operating systems supported: Windows Server 2012 Core, Windows Server 2016, Windows Server 2019, Windows Server 2022, Windows Server 2008, Windows Server 2003
Operating system version: 4.1
Operating system installed: ADM
Linux operating systems supported: Yes
Mac operating systems supported: macOS
Windows operating systems supported: Yes
Storage
Supported file systems: FAT32, BTRFS, ext4, HFS+, ext3, NTFS, exFAT
Number of M.2 (M & B) slots: 4
Installed storage drive type: HDD
Storage drive interface: M.2, Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported: 3.5", M.2, 2.5
Storage drives installed: Yes
RAID support: Yes
Supported storage drive types: HDD & SSD
RAID levels: 1, 10, 0, 6, JBOD, 5
Number of storage drives supported: 6
Ports & interfaces
USB port: Yes
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.0b
HDMI ports quantity: 1
Logistics data
Harmonized System (HS) code: 84714100
