Design Rack mounting: No Housing material: Plastic Cable length: 1.2 m Remote switch cable length: 1.8 m Product colour: Black Wired remote switch: Yes LED indicators: Yes
Power Input voltage: 5 V Power source: DC USB powered: Yes Power consumption (typical): 1.38 W
Operational conditions Operating relative humidity (H-H): 0 - 80% Storage temperature (T-T): -20 - 60 °C Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Depth: 83.4 mm Height: 30.4 mm Width: 84.2 mm Weight: 360 g
Network Ethernet LAN: No
System requirements Mac operating systems supported: Yes Windows operating systems supported: Yes Linux operating systems supported: Yes
Performance Hot-Plug support: Yes HDCP: Yes Maximum resolution: 4096 x 2160 pixels Video bandwidth: 30 Hz HD type: 4K Ultra HD
Packaging data Package weight: 435 g Package width: 55 mm Package depth: 155 mm Package height: 225 mm
Packaging content Manual: Yes
Display Built-in display: No
Ports & interfaces Video port type: DisplayPort Keyboard port type: USB Headphone outputs: 1 DisplayPort version: 1.1 Console ports: USB A, DisplayPort, 3.5mm headphone, 3.5mm mic Console USB ports quantity: 2 Number of computers controlled: 2 USB connector type: Micro-USB B, USB Type-A Mouse port type: USB Number of microphone inputs: 1 Audio connections: Yes USB 2.0 ports quantity: 2 DisplayPorts quantity: 1
Logistics data Master (outer) case length: 389 mm Harmonized System (HS) code: 85176200 Master (outer) case height: 330 mm Master (outer) case net weight: 7.2 kg Master (outer) case gross weight: 9.33 kg Master (outer) case width: 328 mm Products per master (outer) case: 20 pc(s)
Safety warning Warnings: Do not open the appliance without the assistance of a qualified service technician., Risk of electric shock., Ensure that the device is properly cooled during operation.
