Features
3D: Yes
HDCP: Yes
Type: AV transmitter & receiver
Supported video modes: 1080p, 1080i
Maximum transfer distance: 60 m
Material: Metal
Supported graphics resolutions: 1920 x 1080 (HD 1080), 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 1920 x 1200 (WUXGA), 1024 x 768 (XGA)
Maximum resolution: 1920 x 1200 pixels
Product colour: Black
Bandwidth: 225 MHz, 6.75 Gbit/s
Extended display identification data (EDID): Yes
Electrostatic Discharge (ESD) protection: Yes, 15 kV
Cable types supported: Cat5e
Power
Operating voltage (transmitter): 5 V
Operating voltage (receiver): 5 V
Power consumption (TX): 1.04 W
Power consumption (RX): 0.75 W
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage relative humidity (H-H): 0 - 80%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%
Weight & dimensions
Weight: 495 g
Receiver dimensions (WxDxH): 90 x 57.4 x 24 mm
Transmitter weight: 160 g
Receiver weight: 160 g
Transmitter dimensions (WxDxH): 90 x 57.4 x 24 mm
Packaging data
Package height: 160 mm
Package weight: 652 g
Package width: 59 mm
Package depth: 239 mm
Packaging content
Mounting kit: Yes
Cables included: USB
Manual: Yes
AC adapter included: Yes
Ports & interfaces
HDMI in: 1
USB connector type: USB Type-A, USB Type-B
Number of HDMI outputs: 1
DC-in jack: Yes
Connectivity technology: Wired
Logistics data
Master (outer) case length: 490 mm
Master (outer) case height: 338 mm
Master (outer) case width: 315 mm
Products per master (outer) case: 20 pc(s)
Master (outer) case gross weight: 13.5 kg
Master (outer) case net weight: 9.9 kg
