Features
Maximum wind resistance (take-off and landing): 12 m/s
Number of axis: 3
Artificial intelligence (AI) functions: Yes
Maximum Propeller Rotational Speed: 7500 rpm
Sensor system type : Multidirectional
Start-up time: 15 s
BDS: Yes
Autonomous Flight Planning: Yes
Obstacle detection: Yes
Laser measuring range: 5 - 1200 m
Interference protection: Yes
Frequency band: 2.4 GHz/5.2 GHz/5.8 GHz/900 MHz
GPS (satellite): Yes
Galileo: Yes
Maximum flight time: 42 min
GLONASS: Yes
Maximum speed: 23 m/s
Maximum operating distance: 25000 m
Maximum take-off height: 4500 m
Maximum angular velocity: 120°/s
Memory
Built-in memory capacity: 128 GB
Maximum memory card size: 1 TB
Compatible memory cards: MicroSD (TransFlash)
Memory card slot(s): Yes
Design
Number of propeller blades: 2
Wide-angle camera: Yes
Zoom camera (telephoto): Yes
Thermal imaging camera: Yes
Ventilation type: Passive
Takeoff weight (max): 1999 g
Number of rotors: 4 rotors
Number of cameras: 3
Type: Drone
Propeller material: Carbon fiber, Nylon
Product colour: Grey
Replaceable battery: Yes
Strobe: Yes
Laser distance measurer: Y
Power
Total output power: 120 W
USB port voltage: 17 V
AC adapter input voltage: 100 - 240 V
AC adapter frequency: 50/60 Hz
Charging via USB C: Yes
Operational conditions
Operating temperature (transmitter): -20 - 40 °C
International Protection (IP) code: IP43
Operating temperature (T-T): -25 - 50 °C
Management features
Obstacle sensing system: Yes
Auto landing function: Yes
Auto return function: Yes
Flight modes: Follow Me mode
Auto takeoff function: Yes
Moving control functions: Downward, Turn left, Upward, Backward, Forward, Turn right
Cooperation with applications: Android
Dedicated application: Autel Enterprise
Weight & dimensions
Transmitter weight: 1,195 kg
Product dimensions when open (WxDxH): 563 x 657 x 147 mm
Wheelbase diagonal: 46,7 cm
Transmitter dimensions: 269 x 302 x 87 mm
Propeller diameter: 27,94 cm
Weight: 1,665 kg
Packaging content
Screwdriver: Yes
Number of drones: 1
Leash included: Yes
Set contents: Autel V3 controller
Number of batteries: 1
Carrying case: Yes
Battery charger included: Yes
Cables included: USB Type-C to USB Type-A
Manual: Yes
Spare propeller(s) included: 1 pairs
Camera
Artificial intelligence (AI) functions: Yes
Effective sensor resolution (thermal module): 640 x 512 pixels
Thermovision : Y
Sensor: CMOS 1/2"
Temperature measuring range: -20°C do 150°C / 0°C do 550°C
Maximum hybrid zoom : 160x
Focal length of zoom camera (telephoto): 35 mm, equivalent: 64-234mm
Camera resolution: 8000 x 6000 pixels
Accuracy of temperature measurement: ±2°C
Digital zoom: 16x
Supported video modes: 4K, 1080p
Optical zoom: 2,7 - 10x
Maximum frame rate: 30 fps
Live view: Yes
ISO sensitivity (min): 100
Fixed focal length: 24 mm
Megapixel (approx.): 48 MP
ISO sensitivity (max): 6400
Video streaming: Yes
Aperture: F2.8 - F4.8
Battery
Battery voltage (transmitter): 11,55 V
Rated capacity (mAh): 9248 mAh
Battery voltage: 14.76 V
Battery capacity: 8070 mAh
Battery technology: Lithium Polymer (LiPo)
Battery capacity (transmitter): 5800 mAh
Battery life (transmitter): 2,5 - 4 h
Other features
Operated via Android devices: Yes
Remotely operated: Yes
Applications supported: Autel Sky
Easy to use: Yes
Safety warning
Warnings: The product contains lithium-ion batteries, which may be flammable. Avoid damaging them., In the event of a product failure, follow local regulations for the disposal of electronic devices and batteries., The drone may pose health and safety risks if used incorrectly. Read the user manual before use.
Transmitter
Display resolution: 2048 x 1536 px
Built-in WiFi: Yes
Removable battery: Yes
USB 2.0 Type-A ports quantity: 1
Latency: <150 ms
Image transmission - transmitter power (EIRP) : CE: ≤20dBm -2.4G, ≤14dBm - 5.8G, FCC: ≤33dBm, SRRC: ≤20dBm - 2.4G, ≤33dBm - 5.8G/5.7G
Bluetooth transmitter power: 20 dBm
Transmission range: 15 km (FCC), 8 km (CE)
Refresh rate : 60 Hz
Housing material: Polycarbonate (PC), ABS
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Built-in display: Yes
Display diagonal: 20.1 cm (7.9")
Touchscreen: Yes
Power Delivery: Yes
Bluetooth version: 5.0
Display type: TFT-LCD
Bluetooth: Yes
Antennas quantity: 2
Built-in battery: Yes
HDMI ports quantity: 1
Replaceable battery: No
Charging via USB C: Yes
Maximum resolution & refresh rate (HDMI): 1920x1080@60Hz
Operating frequency (RF): 902-928 MHz, (FCC), 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmission system: Autel SkyLink 3.0
