Design
Tilt angle range: -30 - 90°
Pan range: -170 - 170°
Product colour: Black
LED indicators: Status
Web-based management: Yes
Country of origin: Taiwan
Mounting type: Stand
Power
AC input frequency: 50/60 Hz
Input current: 2 A
AC input voltage: 100 - 240 V
Power source type: AC
DC input voltage: 12 V
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 20 - 80%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Depth: 153 mm
Height: 182 mm
Width: 143 mm
Weight: 1.5 kg
Remote control dimensions (W x H x D): 200 x 50 x 21 mm
Network
Supported network protocols: RTSP, RTMP
Ethernet LAN data rates: 10,100,1000 Mbit/s
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Minimum RAM: 8192 MB
Minimum processor: Intel Core i5-4460
Minimum processor speed: 3.2 GHz
Other operating systems supported: ChromeOS
Minimum processor family: Core i5
Performance
Plug and Play: Yes
Remote control type: IR
Remote control function: Yes
Packaging data
Package weight: 3.8 kg
Package depth: 264 mm
Package type: Box
Package height: 284 mm
Package width: 518 mm
Packaging content
Cables included: AC, USB
Mounting kit: Yes
Quick start guide: Yes
Remote control included: Yes
Warranty card: Yes
Power supply included: Yes
Cable ties included: Yes
Screws included: Yes
Audio
Built-in microphone: Yes
Built-in speaker(s): Yes
Ports & interfaces
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 1
Camera
Wide Dynamic Range (WDR): Yes
White balance: Auto, Manual
Optical zoom: 12x
Focal length range: 3.9 - 46.8 mm
Horizontal field of view: 72.8°
Aperture range (F-F): 1.6 - 2.8
Flip & mirror: Yes
Number of camera presets: 10
PTZ control: Yes
Combined zoom: 36x
Field of view (FOV) angle: 80.5°
Vertical field of view: 44.1°
Closest focusing distance: 1 m
Megapixel (approx.): 8 MP
Logistics data
Harmonized System (HS) code: 8517691000
Products per pallet: 84 pc(s)
Products per master (outer) case: 2 pc(s)
Video
HD type: Full HD
Video formats supported: YUV, NV12, M-JPEG, YUY2
Supported video modes: 480p, 1080p, 360p, 900p, 720p, 240p
Maximum frame rate: 60 fps
Maximum video resolution: 1920 x 1080 pixels
