Design
Pan range: -170 - 170°
Product colour: Black
Tilt angle range: -30 - 90°
Country of origin: Taiwan
Power
AC input voltage: 100 - 240 V
Operating current: 2 A
Power source type: AC, PoE
AC input frequency: 50 - 60 Hz
Operating voltage: 12 V
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 20 - 80%
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Width: 150 mm
Weight: 4.6 kg
Height: 194 mm
Depth: 165.5 mm
System requirements
Other operating systems supported: ChromeOS
Minimum processor speed: 3.2 GHz
Windows operating systems supported: Windows 7, Windows 11, Windows 10
Minimum processor: Intel Core i5-4460
Minimum RAM: 4096 MB
Mac operating systems supported: Yes
Performance
Cable lock slot: Yes
Cable lock slot type: Kensington
Packaging data
Package weight: 10.9 kg
Package type: Box
Package height: 525 mm
Package depth: 293 mm
Package width: 275 mm
Packaging content
HDMI: Yes
Power adapter included: Yes
Ports & interfaces
RS-232 output ports: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 1
HDMI ports quantity: 1
RJ-45 ports quantity: 1
RS-232 input ports: 1
Camera
Optical zoom: 12x
Horizontal field of view: 78°
Combined zoom: 36x
Focal length range: 3.4 - 40.3 mm
Vertical field of view: 52°
Sensor type: Exmor
Zoom capability: Yes
Camera type: Dual camera
Digital zoom: 3x
Closest focusing distance: 1.5 m
Aperture range (F-F): 1.8 - 3.6
Field of view (FOV) angle: 95°
Logistics data
Products per pallet: 48 pc(s)
Harmonized System (HS) code: 8517691000
Products per master (outer) case: 2 pc(s)
Video
Supported video modes: 480p, 1080p, 540p, 360p, 900p, 720p
HD type: 4K Ultra HD
Maximum frame rate: 60 fps
Resolution at capture speed: 3840x2160@30fps
Maximum video resolution: 3840 x 2160 pixels
