Certification: 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35, IEC/EN 62368-1, 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35, NIST SP500-267
Design
LED indicators: Status
Product colour: White
Wall mountable: Yes
Power
Power consumption (typical): 4.7 W
Security
IP address filtering: Yes
Security algorithms: HTTPS
Video motion detection: Yes
Active tampering alarm: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 85%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Weight & dimensions
Height: 37 mm
Width: 187 mm
Weight: 650 g
Network
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Power over Ethernet (PoE): Yes
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.3at, IEEE 802.3af
Performance
Card reader integrated: Yes
Internal memory: 1024 MB
Flash memory: 512 MB
Compatible memory cards: MicroSDHC, MicroSD (TransFlash), MicroSDXC
PTZ control: Yes
Image settings: Mirroring, Color, Contrast, Brightness, Sharpness, Compression, Privacy mask, Rotation
Packaging content
Manual: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
BNC input ports: 4
RS-485 ports: 2
Video
Maximum frame rate: 30 fps
Video compression formats: MPEG4, H.265, AVC, HEVC, H.264
Channels quantity: 4 channels
PAL resolutions: 720x576 pixels
NTSC resolutions: 720x480 pixels
Maximum video resolution: 720 x 576 pixels
