Design
LED indicators: Yes
Product colour: White
Mounting type: Ceiling/wall
Housing material: Aluminium
IK code: IK10
Form factor: Dome
International Protection (IP) code: IP66
Protection features: Water resistant, Dust resistant
Power
Power consumption (typical): 7.9 W
Power source type: PoE
Power consumption (max): 15.5 W
Security
IP address filtering: Yes
HTTPS encryption: Yes
Security algorithms: HTTPS, 802.1x RADIUS
Pixel counter: Yes
Alert notification type: E-mail, Text alert message
Digest authentication: Yes
Active tampering alarm: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 100%
Operating temperature (T-T): -40 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 850 g
Height: 69 mm
Diameter: 14.9 cm
Network
Quality of Service (QoS) support: Yes
Wi-Fi: No
Networking standards: IEEE 802.3at
Ethernet LAN: Yes
Bluetooth: No
Certification: EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2,
FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A,
RCM AS/NZS CISPR 32 Class A, KS C9832 Class A, KS C9835
Performance
Alarm input/output: Yes
Infrared (IR) cut-off filter: Yes
PTZ modes: Digital PTZ
Languages support: French, English, Italian, Traditional Chinese, Portuguese, Simplified Chinese, German, Polish, Japanese, Russian, Korean
Number of languages: 12
Day/night mode: Yes
Placement supported: Indoor & outdoor
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Connectivity technology: Wired
Packaging content
Manual: Yes
Mounting brackets included: Yes
Mounting kit: Yes
Drilling template included: Yes
Number of cameras: 1
Audio
Audio detection: Yes
Audio formats supported: OPUS, LPCM, ADPCM, AAC-LC, G.711, G.726
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in HDD: No
Card reader integrated: Yes
Internal memory: 2000 MB
Flash memory: 1000 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0.04 lx
Camera pan control: Yes
Camera tilt control: Yes
Field of view (FOV) angle: 183°
Camera shutter speed: 1/22000 - 1 s
Lens viewing angle, horizontal: 183°
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 1.7 mm (1 / 1.7")
Number of sensors: 1
Video
Frame rate: 30 fps
Privacy masking: Yes
Maximum resolution: 2880 x 2880 pixels
Total megapixels: 12 MP
Image quality adjustment: Contrast, Brightness
Video recording: Yes
Video streaming: Yes
Night vision
LED type: IR
Night vision: Yes
Lens system
Auto focus: No
Focal length range: 1.3 mm
Number of lenses: 1
Fixed focus: Yes
Zoom capability: Yes
