Design
Housing material: Plastic, Aluminium
IK code: IK08
International Protection (IP) code: IP66, IP67
Product colour: White
Mounting type: Ceiling/wall
Protection features: Water resistant, Dust resistant, Vandal proof
Form factor: Bullet
Power
Power consumption (max): 12.95 W
Power source type: PoE
Power consumption (typical): 5 W
Security
Security algorithms: EAP-TLS, SSH, HTTPS, 802.1x RADIUS
Video motion detection: Yes
IP address filtering: Yes
Password protection: Yes
HTTPS encryption: Yes
Active tampering alarm: Yes
Alert notification type: E-mail
Operational conditions
Operating relative humidity (H-H): 10 - 100%
Operating temperature (T-T): -30 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Weight & dimensions
Weight: 491 g
Length: 170 mm
Diameter: 10.1 cm
Network
Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Certification: CISPR 24, CISPR 35, EN 55032 Class A, EN 55035,
EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A,
ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35,
RCM AS/NZS CISPR 32 Class A, VCCI Class A
IEC/EN 62368-1, IEC 62471, IS 13252
IEC 60068-2-X, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK08
NIST SP500-267
Performance
Type: IP security camera
Day/night mode: Yes
Languages support: Italian, Traditional Chinese, German, Korean, Polish, Japanese, Russian, French, Portuguese, Spanish, Simplified Chinese, English
PTZ modes: Digital PTZ
Wide Dynamic Range (WDR): Yes
Placement supported: Outdoor
Number of languages: 12
Infrared (IR) cut-off filter: Yes
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Storage
Built-in HDD: No
Flash memory: 512 MB
Card reader integrated: Yes
Internal memory: 1024 MB
Compatible memory cards: MicroSDHC, MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0 lx
White balance: Auto
Camera shutter speed: 1/38500 - 1/5 s
Lens viewing angle, horizontal: 130°
Lens viewing angle, vertical: 81°
Other features
Doesn't contain: PVC, BFR
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Sensor type: CMOS
Video
Video compression formats: H.265, M-JPEG, H.264
Privacy masking: Yes
Image stabilizer: Yes
Total megapixels: 4 MP
Text caption overlay: Yes
Supported video modes: 1440p
Supported graphics resolutions: 2668 x 1512, 2304 x 1728
Video streaming: Yes
Maximum resolution: 2304 x 1728 pixels
Video intelligence analytic: Yes
Video recording: Yes
Night vision
LED type: IR
Night vision: Yes
Night vision distance: 20 m
Infra-red wavelength: 855 nm
Lens system
Maximum aperture number: 2.1
Closest focusing distance: 0.5 m
Fixed focal length: 2.4 mm
Number of lenses: 1
