Design
IK code: IK08
Form factor: Bullet
International Protection (IP) code: IP66, IP67
Mounting type: Ceiling/wall
Housing material: Aluminium, Plastic
Product colour: Black
Power
Power consumption (typical): 5 W
Power consumption (max): 12.95 W
Power source type: PoE
Security
IP address filtering: Yes
Alert notification type: E-mail
Video motion detection: Yes
Active tampering alarm: Yes
Password protection: Yes
HTTPS encryption: Yes
Security algorithms: HTTPS, 802.1x RADIUS, SSH, EAP-TLS
Operational conditions
Operating relative humidity (H-H): 10 - 100%
Storage temperature (T-T): -40 - 65 °C
Operating temperature (T-T): -30 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Diameter: 10.1 cm
Length: 170 mm
Weight: 491 g
Network
Wi-Fi: No
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Bluetooth: No
Networking standards: IEEE 802.3af, IEEE 802.3, IEEE 802.3at
Certification: CISPR 24, CISPR 35, EN 55032 Class A, EN 55035,
EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A,
ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35,
RCM AS/NZS CISPR 32 Class A, VCCI Class A
IEC/EN 62368-1, IEC 62471, IS 13252
IEC 60068-2-X, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK08
NIST SP500-267
Performance
Type: IP security camera
Day/night mode: Yes
Languages support: German, Polish, Japanese, Russian, Italian, Traditional Chinese, English, Portuguese, Simplified Chinese, Spanish, French, Korean
Wide Dynamic Range (WDR): Yes
Infrared (IR) cut-off filter: Yes
Number of languages: 12
Placement supported: Indoor & outdoor
PTZ modes: Digital PTZ
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Storage
Built-in HDD: No
Card reader integrated: Yes
Flash memory: 512 MB
Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
Internal memory: 1024 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0 lx
Lens viewing angle, horizontal: 130°
Lens viewing angle, vertical: 81°
White balance: Auto
Camera shutter speed: 1/38500 - 1/5 s
Other features
Doesn't contain: BFR, PVC
Image sensor
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Video compression formats: M-JPEG, H.265, H.264
Video recording: Yes
Frame rate: 30 fps
Supported video modes: 1440p
Privacy masking: Yes
Video intelligence analytic: Yes
Total megapixels: 4 MP
Bit rate control: Variable Bit Rate (VBR)
Video streaming: Yes
Text caption overlay: Yes
Image stabilizer: Yes
Supported graphics resolutions: 2668 x 1512, 2304 x 1728
Maximum resolution: 2304 x 1728 pixels
Night vision
LED type: IR
Infra-red wavelength: 855 nm
Night vision: Yes
Night vision distance: 20 m
Lens system
Maximum aperture number: 2.1
Number of lenses: 1
Fixed focal length: 2.4 mm
Closest focusing distance: 0.5 m
