Design
Housing material: Aluminium, Polycarbonate (PC)
International Protection (IP) code: IP66, IP67
IK code: IK10
Mounting type: Wall
Product colour: White
Form factor: Dome
Power
Power consumption (Power over Ethernet (PoE)): 2.2 W
Power source type: PoE
Power consumption (max): 3.8 W
Security
IP address filtering: Yes
Video motion detection: Yes
Pixel counter: Yes
Network access storage (NAS): Yes
HTTPS encryption: Yes
Password protection: Yes
Active tampering alarm: Yes
Digest authentication: Yes
Operational conditions
Operating temperature (T-T): -30 - 55 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Weight & dimensions
Height: 50 mm
Diameter: 11 cm
Weight: 241 g
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.1x
Bluetooth: No
Wi-Fi: No
Quality of Service (QoS) support: Yes
Certification: CE, ECE, KC, RCM, UL/cUL, UKCA, VCCI, WEEE
Performance
PTZ modes: Digital PTZ
PTZ control: Yes
Built-in processor: Yes
Placement supported: Indoor
Languages support: German, Polish, Japanese, Russian, Finnish, French, Vietnamese, Dutch, Czech, Spanish, Simplified Chinese, Turkish, Thai, Italian, Traditional Chinese, Korean, English, Portuguese, Swedish
Number of languages: 19
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Type: IP security camera
Packaging content: Windows decoder 1-user license, lens tool
Packaging content
Number of cameras: 1
Manual: Yes
Storage
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in HDD: No
Flash memory: 512 MB
Internal memory: 1024 MB
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Pan range: -30 - 30°
Minimum illumination: 0.04 lx
Angle of rotation: 175°
Lens viewing angle, vertical: 47°
Camera tilt control: Yes
Lens viewing angle, horizontal: 88°
Camera pixel size: 2.8 µm
Tilt angle range: 15 - 90°
Camera pan control: Yes
Image sensor
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Sensor type: CMOS
Video
Video compression formats: M-JPEG, H.264, H.265
Frame rate: 30 fps
Privacy masking: Yes
Video streaming: Yes
Total megapixels: 2 MP
Noise reduction technology: 2D noise reduction, 3D noise reduction
Noise reduction: Yes
Video recording: Yes
Maximum resolution: 1920 x 1080 pixels
Night vision
Night vision: No
Lens system
Maximum aperture number: 2
Zoom capability: Yes
Lens diameter: 3.6 mm
