Design
Form factor: Dome
Housing material: Aluminium, Polycarbonate (PC)
International Protection (IP) code: IP42
IK code: IK08
Mounting type: Ceiling/wall
Product colour: White
Power
Power consumption (Power over Ethernet (PoE)): 3 W
Power source type: PoE
Power consumption (max): 4.8 W
Security
Video motion detection: Yes
Mirror: Yes
Password protection: Yes
Active tampering alarm: Yes
Digest authentication: Yes
Pixel counter: Yes
Network access storage (NAS): Yes
IP address filtering: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -30 - 65 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 85%
Weight & dimensions
Height: 71 mm
Diameter: 12 cm
Weight: 356 g
Network
Ethernet LAN: Yes
Wi-Fi: No
Networking standards: IEEE 802.3at, IEEE 802.1x, IEEE 802.3af
Bluetooth: No
Quality of Service (QoS) support: Yes
Ethernet interface type: Fast Ethernet
Certification: CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Performance
Infrared (IR) cut-off filter: Yes
Languages support: Turkish, Thai, Simplified Chinese, French, Vietnamese, English, Finnish, German, Polish, Japanese, Russian, Dutch, Czech, Spanish, Portuguese, Swedish, Korean, Italian, Traditional Chinese
Number of languages: 19
Type: IP security camera
Connectivity technology: Wired
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor
PTZ modes: Digital PTZ
PTZ control: Yes
Built-in processor: Yes
Packaging content: Owner authentication key, virtual client license for H.264/H.265
Packaging content
Number of cameras: 1
Manual: Yes
Storage
Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
Built-in HDD: No
Internal memory: 2048 MB
Flash memory: 512 MB
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Camera
Camera pan control: Yes
Camera tilt control: Yes
Lens viewing angle, vertical: 50 - 26°
Lens viewing angle, horizontal: 93 - 47°
Tilt angle range: -40 - 65°
Minimum illumination: 0.24 lx
Pan range: -180 - 180°
Camera shutter speed: 1/71500 - 1/5 s
Angle of rotation: 105°
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Privacy masking: Yes
Video recording: Yes
Noise reduction: Yes
Maximum resolution: 3840 x 2160 pixels
Video streaming: Yes
Video compression formats: H.264, M-JPEG, H.265
Total megapixels: 8 MP
Noise reduction technology: 2D noise reduction, 3D noise reduction
Frame rate: 15 fps
Night vision
Night vision: No
Lens system
Zoom capability: Yes
Minimum aperture number: 1.7
Maximum aperture number: 2.6
