Design
Mounting type: Ceiling/wall
Housing material: Polycarbonate (PC), Aluminium
IK code: IK08
Product colour: White
Form factor: Dome
International Protection (IP) code: IP42
Power
Power consumption (Power over Ethernet (PoE)): 5 W
Power consumption (max): 9.7 W
Power source type: PoE
Security
Video motion detection: Yes
Mirror: Yes
IP address filtering: Yes
Digest authentication: Yes
Network access storage (NAS): Yes
Active tampering alarm: Yes
Password protection: Yes
Pixel counter: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -30 - 65 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Diameter: 12 cm
Height: 71 mm
Weight: 375 g
Network
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Bluetooth: No
Networking standards: IEEE 802.3at, IEEE 802.1x, IEEE 802.3af
Ethernet interface type: Fast Ethernet
Wi-Fi: No
Certification: CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Performance
PTZ control: Yes
Day/night mode: Yes
PTZ modes: Digital PTZ
Infrared (IR) cut-off filter: Yes
Built-in processor: Yes
Languages support: Dutch, Czech, Spanish, English, Finnish, Korean, Swedish, French, Vietnamese, Turkish, Thai, German, Polish, Japanese, Russian, Portuguese, Simplified Chinese, Italian, Traditional Chinese
Number of languages: 19
Type: IP security camera
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor
Packaging content: Owner authentication key, virtual client license for H.264/H.265
Packaging content
Number of cameras: 1
Manual: Yes
Storage
Built-in HDD: No
Internal memory: 2048 MB
Flash memory: 512 MB
Card reader integrated: Yes
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Camera
Pan range: -180 - 180°
Minimum illumination: 0.24 lx
Angle of rotation: 105°
Camera shutter speed: 1/71500 - 1/5 s
Camera pan control: Yes
Tilt angle range: -40 - 65°
Camera tilt control: Yes
Lens viewing angle, horizontal: 93 - 47°
Lens viewing angle, vertical: 50 - 26°
Image sensor
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Progressive scan: Yes
Video
Video compression formats: H.264, H.265, M-JPEG
Video recording: Yes
Total megapixels: 8 MP
Noise reduction: Yes
Privacy masking: Yes
Video streaming: Yes
Frame rate: 15 fps
Noise reduction technology: 2D noise reduction, 3D noise reduction
Maximum resolution: 3840 x 2160 pixels
Night vision
Night vision: No
Lens system
Minimum aperture number: 1.7
Zoom capability: Yes
Maximum aperture number: 2.6
