Design
IK code: IK10
Product colour: Black, White
International Protection (IP) code: IP66
LED indicators: Yes
Form factor: Dome
Housing material: Polycarbonate (PC), Aluminium
Mounting type: Ceiling/wall
Power
Power source type: PoE
Power consumption (typical): 5.7 W
Power consumption (max): 12.95 W
Security
Privacy protection: Yes
IP address filtering: Yes
Security algorithms: EAP-TLS, 256-bit AES-XTS, TLS
HTTPS encryption: Yes
Alert notification type: E-mail
Password protection: Yes
Pixel counter: Yes
Active tampering alarm: Yes
Video motion detection: Yes
Digest authentication: Yes
Human and vehicle targets classification: Yes
Operational conditions
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Operating temperature (T-T): -40 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Behavior analysis: Line crossing detection
Weight & dimensions
Width: 149 mm
Depth: 149 mm
Weight: 860 g
Height: 70 mm
Network
Quality of Service (QoS) support: Yes
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Networking standards: IEEE 802.3af, IEEE 802.3at
Streaming method: Multicast
Performance
PTZ control: Yes
PTZ modes: Preset point, Digital PTZ
Languages support: Turkish, Thai, German, Polish, Japanese, Russian, Portuguese, Korean, Italian, Traditional Chinese, Finnish, Dutch, Czech, Spanish, Swedish, French, Vietnamese, English, Simplified Chinese
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Type: IP security camera
Placement supported: Indoor
Infrared (IR) cut-off filter: Yes
Number of languages: 20
Day/night mode: Yes
Packaging content
Number of cameras: 1
Manual: Yes
Audio
Audio system: 2-way
Storage
Internal memory: 2048 MB
Flash memory: 8192 MB
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Camera
Camera shutter speed: 1/33500 - 0.2 s
Minimum illumination: 0.03 lx
Lens viewing angle, horizontal: 182°
Lens viewing angle, vertical: 182°
Other features
Doesn't contain: PVC/BFR
Image sensor
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Video
Frame rate: 60 fps
Bit rate control: Variable Bit Rate (VBR)
Total megapixels: 6 MP
Maximum resolution: 2160 x 2160 pixels
Text caption overlay: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Supported graphics resolutions: 384 x 288, 2560 x 1920, 256 x 144, 1920 x 1440, 2560 x 1440
Noise reduction: Yes
Image quality adjustment: Saturation, Brightness, Sharpness, Contrast
Video streaming: Yes
Night vision
Night vision distance: 20 m
Night vision: Yes
Infra-red wavelength: 850 nm
LED type: IR
Lens system
Fixed focal length: 2.2 mm
Fixed focus: Yes
Number of lenses: 1
Sustainability
Compliance certificates: RoHS
