Features
License plate recognition: Yes
Design
International Protection (IP) code: IP66
Form factor: Dome
Product colour: White, Black
IK code: IK09
Mounting type: Ceiling
Housing material: Polycarbonate (PC), Plastic
Power
Power source type: PoE
Power consumption (max): 11.7 W
Power consumption (typical): 4.2 W
Power consumption: 3.8 mA
Power consumption (Power over Ethernet (PoE)): 12.95 W
Security
Security algorithms: EAP-TLS, HTTPS, 802.1x RADIUS, MSCHAPv2, PEAP, TLS
Pixel counter: Yes
Human and vehicle targets classification: Yes
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Line crossing detection, Face detection, Human detection, Moving object
Alert notification type: E-mail
Video motion detection: Yes
Active tampering alarm: Yes
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 15 - 100%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 165 mm
Depth: 165 mm
Weight: 1 kg
Height: 150 mm
Network
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.3af, IEEE 802.3at
Streaming method: Multicast
Certification: CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Performance
Connectivity technology: Wired
Type: IP security camera
Day/night mode: Yes
PTZ control: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Preset points: Yes
Packaging content
Manual: Yes
Number of cameras: 1
Audio
Audio system: 2-way
Audio formats supported: PCM, AAC-LC, LPCM, G.711
Signal-to-Noise Ratio (SNR): 55 dB
Audio system full duplex: Yes
Sample rate: 48 kHz
Audio detection: Yes
Storage
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Flash memory: 8192 MB
ROM capacity: 1024 MB
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Terminal block port: Yes
Camera
Tilt angle range: 0 - 90°
Lens viewing angle, horizontal: 59.1 - 6.5°
Lens viewing angle, vertical: 35 - 3.67°
Camera pixel size: 1.998 µm
Pan range: 0 - 360°
Camera shutter speed: 1/27000 - 0.2 s
Tilt speed: 150 °/sec
Minimum illumination: 0.01 lx
Pan speed: 150 °/sec
Camera tilt control: Yes
Camera pan control: Yes
Other features
Doesn't contain: PVC/BFR
Image sensor
Optical sensor size: 25.4 / 3 mm (1 / 3")
Sensor type: CMOS
Number of sensors: 1
Video
Maximum resolution: 2688 x 1512 pixels
Supported graphics resolutions: 1600 x 1200 (UXGA), 320 x 180, 160 x 120
Frame rate: 60 fps
Video streaming: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Total megapixels: 4 MP
Video formats supported: H.264, HEVC, AVC, MPEG4, H.265, M-JPEG
Noise reduction: Yes
Image quality adjustment: Saturation, Contrast, Sharpness, Brightness
Gain control type: Auto
Text caption overlay: Yes
Privacy masking: Yes
Lens system
Zoom capability: Yes
Recognize distance (tele): 186 m
Detect distance (tele): 938 m
Maximum aperture number: 3
Minimum aperture number: 1.6
Focal length range: 4.7 - 47 mm
Observe distance (wide): 38 m
Optical zoom: 10x
Detect distance (wide): 96 m
Digital zoom: 12x
Recognize distance (wide): 19 m
Identify distance (wide): 10 m
Identify distance (tele): 93 m
Observe distance (tele): 373 m
Number of lenses: 1
Auto focus: Yes
Sustainability
Compliance certificates: RoHS, REACH
