Design
Product colour: White, Black
Form factor: Box
Housing material: Aluminium
Fog proof: Yes
Mounting type: Ceiling/wall
Power
Power source type: DC, PoE
Power consumption (typical): 3.15 W
Power consumption (max): 7.76 W
DC output voltage: 10, 28
Power consumption (Power over Ethernet (PoE)): 2.97 W
Security
Security algorithms: EAP-TLS, PEAP, TLS, HTTPS, 802.1x RADIUS
Operational conditions
Storage temperature (T-T): -40 - 65 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Weight: 480 g
Depth: 225 mm
Height: 235 mm
Width: 87 mm
Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN: Yes
Certification: UL/cUL, UKCA, CE, KC, EAC, VCCI, RCM
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3,
IS 13252
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
IEC 60068-2-27, IEC 60068-2-78
NIST SP500-267, IPv6 USGv6
ETSI EN 303 645, FIPS 140
Performance
Type: IP security camera
Connectivity technology: Wired
Day/night mode: Yes
PTZ control: Yes
PTZ modes: Preset point, Digital PTZ
Placement supported: Indoor
Wide Dynamic Range (WDR): Yes
Packaging content
Number of cameras: 1
Audio
Audio formats supported: PCM, OPUS, ADPCM, AAC-LC, G.726, LPCM, G.711
Signal-to-Noise Ratio (SNR): 55 dB
Storage
Card reader integrated: Yes
Flash memory: 8192 MB
Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
Internal memory: 1024 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
RS-485 ports: 2
Camera
Lens viewing angle, vertical: 64 - 15°
Lens viewing angle, horizontal: 121 - 26°
Camera pixel size: 2.9 µm
Minimum illumination: 0.005 lx
Camera shutter speed: 1/37000 - 2 s
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Video
Maximum resolution: 1920 x 1080 pixels
Video compression formats: MPEG4, M-JPEG, H.264, H.265
Noise reduction: Yes
Video streaming: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Total megapixels: 2 MP
Frame rate: 60 fps
Image stabilizer: Yes
Privacy masking: Yes
Gain control type: Auto
Night vision
LED type: IR
Night vision: Yes
Lens system
Focal length range: 2.8 - 13 mm
Auto focus: Yes
