Design
Housing material: Aluminium
Fog proof: Yes
Mounting type: Ceiling/wall
Form factor: Box
International Protection (IP) code: IP66, IP67
Product colour: White, Black
Power
DC output voltage: 10, 28
Power source type: DC, PoE
Power consumption (max): 25.5 W
Power consumption (typical): 3.6 W
Security
Security algorithms: PEAP, TLS, HTTPS, 802.1x RADIUS, EAP-TLS
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Network
Ethernet LAN: Yes
Certification: UL/cUL, CE, KC, EAC, VCCI, RCM
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3,
IS 13252
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
IEC 60068-2-27, IEC 60068-2-78
NIST SP500-267, IPv6 USGv6
ETSI EN 303 645, FIPS 140
Performance
Placement supported: Indoor
Day/night mode: Yes
PTZ modes: Preset point, Digital PTZ
PTZ control: Yes
Type: IP security camera
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Packaging content
Number of cameras: 1
Storage
Internal memory: 1024 MB
Card reader integrated: Yes
Flash memory: 8192 MB
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Ports & interfaces
RS-485 ports: 2
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0.05 lx
Camera shutter speed: 1/37000 - 2 s
Lens viewing angle, vertical: 64 - 15°
Camera pixel size: 2.9 µm
Lens viewing angle, horizontal: 121 - 26°
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Video compression formats: H.264, H.265
Noise reduction: Yes
Privacy masking: Yes
Video streaming: Yes
Image stabilizer: Yes
Total megapixels: 2 MP
Gain control type: Auto
Frame rate: 60 fps
Maximum resolution: 1920 x 1080 pixels
Night vision
Night vision: Yes
Lens system
Focal length range: 2.8 - 13 mm
Auto focus: Yes
