Design
Mounting type: Pole clamp
Housing material: Polycarbonate (PC), Aluminium
International Protection (IP) code: IP66, IP67
IK code: IK10
Form factor: Bullet
Product colour: White
LED indicators: Yes
Power
DC output voltage: 10, 12, 15, 16, 24, 28
Power consumption (max): 12.95 W
Power source type: DC, PoE
Security
Video motion detection: Yes
Pixel counter: Yes
Network access storage (NAS): Yes
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 100%
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 65 °C
Management features
Cloud-managed: Yes
Weight & dimensions
Weight: 1.4 kg
Network
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Wi-Fi: No
Bluetooth: No
Networking standards: IEEE 802.1x, IEEE 802.3at, IEEE 802.1AE, IEEE 802.3af, IEEE 802.1ar
Quality of Service (QoS) support: Yes
Performance
Placement supported: Outdoor
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Wide Dynamic Range (WDR): Yes
PTZ control: Yes
Alarm input/output: Yes
Dynamic range: 120 dB
Built-in processor: Yes
Processor model: ARTPEC-9
Type: IP security camera
Connectivity technology: Wired
Packaging content
Manual: Yes
Number of cameras: 1
Mounting kit: Yes
Audio
Audio system full duplex: Yes
Audio system: 2-way
Storage
Flash memory: 8192 MB
Compatible memory cards: MicroSDHC, MicroSD (TransFlash), MicroSDXC
Card reader integrated: Yes
RAM capacity: 2048 MB
Built-in HDD: No
Ports & interfaces
Microphone in: Yes
Terminal block port: Yes
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Camera
Lens viewing angle, vertical: 62 - 26°
Camera shutter speed: 1/66500 - 2 s
Camera pixel size: 2.9 µm
Lens viewing angle, horizontal: 114 - 46°
Minimum illumination: 0.01 lx
Image sensor
Progressive scan: Yes
Number of sensors: 1
Optical sensor size: 25.4 / 1.2 mm (1 / 1.2")
Sensor type: CMOS
Video
Total megapixels: 8 MP
Image quality adjustment: White balance, Saturation, Sharpness, Contrast, Brightness
Video compression formats: H.264, H.265, AV1, M-JPEG
Video streaming: Yes
Video recording: Yes
Gain control type: Auto
Frame rate: 60 fps
Text caption overlay: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Noise reduction: Yes
Image stabilizer: Yes
Maximum resolution: 3840 x 2160 pixels
Night vision
LED type: IR
Night vision distance: 50 m
Night vision: Yes
Infra-red wavelength: 850 nm
Lens system
Focal length range: 5.9 - 13.8 mm
Minimum aperture number: 1.5
Auto focus: Yes
Zoom capability: Yes
Maximum aperture number: 2.8
