Design
IK code: IK10
International Protection (IP) code: IP54
Form factor: Dome
Housing material: Plastic, Polycarbonate (PC)
Product colour: White
LED indicators: Yes
Mounting type: Ceiling/Wall/Pole
Power
Power consumption (max): 10 W
Power source type: DC, PoE
Power consumption (typical): 3.4 W
DC output current: 0.025 A
DC output voltage: 12
Security
Network access storage (NAS): Yes
Pixel counter: Yes
Video motion detection: Yes
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 85%
Storage temperature (T-T): -40 - 65 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Cloud-managed: Yes
Weight & dimensions
Weight: 800 g
Network
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Quality of Service (QoS) support: Yes
Wi-Fi: No
Bluetooth: No
Networking standards: IEEE 802.3at, IEEE 802.1AE, IEEE 802.3af, IEEE 802.1x, IEEE 802.1ar
Performance
Built-in processor: Yes
Processor model: ARTPEC-9
Wide Dynamic Range (WDR): Yes
PTZ control: Yes
Type: IP security camera
Connectivity technology: Wired
Placement supported: Indoor
Day/night mode: Yes
Dynamic range: 120 dB
Alarm input/output: Yes
Infrared (IR) cut-off filter: Yes
Packaging content
Manual: Yes
Number of cameras: 1
Mounting kit: Yes
Audio
Audio system: 2-way
Audio system full duplex: Yes
Storage
Compatible memory cards: MicroSD (TransFlash), MicroSDXC, MicroSDHC
Card reader integrated: Yes
Flash memory: 8192 MB
Built-in HDD: No
RAM capacity: 2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
DC-in jack: Yes
Terminal block port: Yes
Camera
Minimum illumination: 0.02 lx
Camera shutter speed: 1/37000 - 2 s
Angle of rotation: 95°
Pan range: -190 - 190°
Tilt angle range: -45 - 80°
Camera pixel size: 2.9 µm
Camera tilt control: Yes
Lens viewing angle, horizontal: 100 - 32°
Lens viewing angle, vertical: 52 - 18°
Camera pan control: Yes
Image sensor
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Progressive scan: Yes
Number of sensors: 1
Video
Total megapixels: 2 MP
Frame rate: 60 fps
Maximum resolution: 1920 x 1080 pixels
Noise reduction: Yes
Video compression formats: H.265, H.264, AV1, M-JPEG
Noise reduction technology: 2D noise reduction, 3D noise reduction
Video streaming: Yes
Image quality adjustment: Sharpness, Contrast, Saturation, White balance, Brightness
Video recording: Yes
Text caption overlay: Yes
Gain control type: Auto
Night vision
LED type: IR
Night vision distance: 40 m
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Zoom capability: Yes
Minimum aperture number: 1.4
Detect distance (tele): 135 m
Detect distance (wide): 48 m
Recognize distance (tele): 27 m
Focal length range: 3.4 - 9.8 mm
Maximum aperture number: 2.7
Recognize distance (wide): 9.6 m
Observe distance (tele): 54 m
Observe distance (wide): 19 m
Identify distance (tele): 14 m
Auto focus: Yes
Identify distance (wide): 4.8 m
