Design
IK code: IK10
International Protection (IP) code: IP66, IP67
Form factor: Dome
Product colour: White
Mounting type: Wall/Pole
Power
Power consumption (typical): 5.5 W
Power consumption (max): 12.9 W
Power source type: PoE
Security
Security algorithms: FIPS 140-3
Operational conditions
Operating relative humidity (H-H): 10 - 100%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Weight & dimensions
Weight: 860 g
Network
Ethernet interface type: 10 Gigabit Ethernet, 100 Gigabit Ethernet
Performance
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Connectivity technology: Wired
Day/night mode: Yes
Placement supported: Outdoor
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 55 dB
Storage
Compatible memory cards: SDXC, MicroSD (TransFlash), SDHC
Card reader integrated: Yes
Flash memory: 8000 MB
RAM capacity: 2000 MB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 56 - 17°
Tilt angle range: -45 - 80°
Lens viewing angle, horizontal: 103 - 29°
Camera pixel size: 2 µm
Minimum illumination: 0.11 lx
Angle of rotation: 95°
Pan range: -190 - 190°
Camera shutter speed: 1/66500 - 2 s
Other features
Doesn't contain: PVC, CFR, Brominated Flame Retardant (BFR)
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Supported graphics resolutions: 2560 x 1600 (WQXGA), 3840 x 2160, 2592 x 1944
Maximum resolution: 3840 x 2160 pixels
Video streaming: Yes
Video formats supported: H.264, H.265, AV1
Total megapixels: 8 MP
Frame rate: 30 fps
Night vision
Night vision: Yes
Lens system
Focal length range: 4.4 - 14.6 mm
Auto focus: Yes
Zoom capability: Yes
