Design
On/off switch: Yes
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Product colour: Black
Power
Power protection features: Over current, Short circuit, Over voltage, Over power, Under power, Surge & inrush protection (SIP), Over total voltage
Total power: 750 W
AC input voltage: 100 - 240 V
Weight & dimensions
Height: 86 mm
Depth: 160 mm
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: ATX
Certificates
Compliance certificates: CB, RoHS, CE, Federal Communications Commission (FCC), cTUVus
Ports & interfaces
EPS power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power connectors (4-pin): 1
PCI Express power connectors (6-pin): 2
CPU power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 2
ATX power connector (12+4 pin): Yes
ATX power connector (20+4 pin): Yes
Number of EPS connectors: 1
PCI Express power connectors (12+4 pin): 1
