Technical details
Doesn't contain: Cadmium, Lead, Mercury
Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Product colour: Black
Illumination: No
Power
Max output current (+5V): 15 A
Combined power (+5Vsb): 15 W
Max output current (-12V): 0.3 A
Max output current (+12V): 62.5 A
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 15 A
Hold time: 16 ms
Power Good signal delay range: 100 - 150 ms
Input current: 10 A
AC input voltage: 100 - 240 V
Total power: 750 W
AC input frequency: 50/60 Hz
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 100 W
Efficiency: 86%
Combined power (+12V): 750 W
Combined power (-12V): 3.6 W
Combined power (+5V): 100 W
Weight & dimensions
Height: 86 mm
Depth: 165 mm
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Bronze
Purpose: PC
Mean time between failures (MTBF): 100000 h
ATX version: 3.1
Bearing technology: Sleeve
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Certificates
Compliance certificates: RoHS, Federal Communications Commission (FCC), RCM
Ports & interfaces
PCI Express power connectors (12+4 pin): 1
Number of SATA power cables: 2
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 55 cm
EPS power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Number of SATA power connectors: 6
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 2
Cabling type: Non-Modular
