Technical details
Doesn't contain: Cadmium, Lead, Mercury
Design
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Illumination: No
On/off switch: Yes
Product colour: Black
Power
Power Good signal delay range: 100 - 150 ms
AC input voltage: 100 - 240 V
Combined power (+12V): 750 W
Efficiency: 86%
Combined power (-12V): 3.6 W
Input current: 10 A
Combined power (+5Vsb): 15 W
Max output current (+5V): 15 A
Max output current (+5Vsb): 3 A
Power protection features: Overheating, Short circuit, Over voltage, Under voltage, Over current, Over power
AC input frequency: 50/60 Hz
Max output current (+12V): 62.5 A
Max output current (+3.3V): 15 A
Combined power (+3.3V): 100 W
Combined power (+5V): 100 W
Max output current (-12V): 0.3 A
Total power: 750 W
Power Factor Correction (PFC) type: Active
Hold time: 16 ms
Weight & dimensions
Depth: 165 mm
Height: 86 mm
Width: 150 mm
Performance
ATX version: 2.0
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Purpose: PC
Bearing technology: Sleeve
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Certificates
Compliance certificates: RCM, RoHS, Federal Communications Commission (FCC)
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
ATX power connector (20+4 pin): Yes
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power connectors (4-pin): 2
Motherboard power cable length: 55 cm
Cabling type: Non-Modular
PCI Express power connectors (12+4 pin): 1
Number of SATA power cables: 2
EPS power connector (4+4 pin): Yes
