Technical details
Warranty period: 3 year(s)
Compliance certificates: RoHS, CE, REACH, UKCA, Federal Communications Commission (FCC)
Power
Power consumption: 280 mA
Power source type: USB
Input voltage: 5 V
Operational conditions
Drop resistance: 1.2 m
Operating relative humidity (H-H): 20 - 95%
Storage temperature (T-T): -20 - 70 °C
Operating temperature (T-T): -10 - 50 °C
Weight & dimensions
Weight: 220 g
Height: 172 mm
Width: 67 mm
Depth: 87 mm
Performance
Mean time between failures (MTBF): 50000 h
International Protection (IP) code: IP52
Protection features: Drop resistant
Housing material: Acrylonitrile butadiene styrene (ABS)
Product colour: Black
Packaging data
Package weight: 320 g
Package height: 108 mm
Cables included: USB Type-A
Package width: 175 mm
Package depth: 80 mm
Ports & interfaces
Connectivity technology: Wired
Cable length: 1.8 m
Standard interfaces: USB
Logistics data
Master (outer) case length: 565 mm
Master (outer) case height: 400 mm
Master (outer) case width: 360 mm
Master (outer) case gross weight: 12.8 kg
Products per master (outer) case: 40 pc(s)
Scanning
Light levels (direct sunlight): 0 - 100000 lx
2D (matrix & stacked) barcodes supported: Grid Matrix Code, Micro QR Code, Han Xin, QR Code, PDF417, Aztec Code, MicroPDF417, Dot Code A, MaxiCode, Data Matrix
Read rate (max): 60 reads/s
Scanner type: 1D/2D
Type: Handheld bar code reader
Linear (1D) barcodes supported: China Post, Code 11, EAN-13, EAN-8, UPC-A, Interleaved 2 of 5, Code 93, Industrial 2 of 5, Codabar, ISSN, Code 128, GS1 Databar Limited, GS1 DataBar Omnidirectional, Telepen, GS1 DataBar Expanded, Code 39 (ASCII), MSI, Matrix 2 of 5, JAN-8, GS1-128 (UCC/EAN-128), UPC-E, JAN-13, Code 39
1D resolution (min): 0.076 mm
Horizontal field of view: 45°
Working distance: 45 cm
Vertical field of view: 36°
Optical sensor resolution (W x H): 1280 x 800 pixels
2D resolution (min): 0.18 mm
Sensor type: LED
