Technical details
Sustainability certificates: ENERGY STAR, ErP, Triman
Design
Fan speed: 0 - 2100 RPM
Product colour: Black
On/off fan switch: Yes
Number of fans: 1 fan(s)
Fan diameter: 13.5 cm
Cooling type: Active
On/off switch: Yes
Power
Combined power (+12V): 850 W
Number of +12V rail(s): 4
Combined power (+5V): 120 W
Combined power (+3.3V): 120 W
Max output current (+12V2): 30 A
AC input voltage: 100 - 240 V
Max output current (+5V): 24 A
Max output current (-12V): 0.5 A
Power protection features: Surge & inrush protection (SIP), Overheating, Under voltage, Over current, Short circuit, Over voltage, Overload
Max output current (+12V4): 35 A
AC input frequency: 50/60 Hz
Max output current (+12V1): 30 A
Maximum input current (@220V): 5 A
Total power: 850 W
Max output current (+12V3): 35 A
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 24 A
Peak power: 950 W
Maximum input current (@110V): 10 A
Power factor: 0.98
Efficiency: 93.8%
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 86 mm
Width: 150 mm
Weight: 2.2 kg
Depth: 175 mm
Performance
80 PLUS certification: 80 PLUS Titanium
ATX version: 3.1
Noise level: 16 dB
Bearing technology: FDB
Purpose: PC
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 100000 h
EPS version: 2.92
Packaging data
Package depth: 126 mm
Package height: 355 mm
Package weight: 3.5 kg
Manual: Yes
Package width: 230 mm
Manual languages: French, Spanish, Italian, Ukrainian, Russian, Simplified Chinese, English, German, Thai, Polish, Japanese
Certificates
Compliance certificates: TÜV mark, WEEE, RoHS, CB, Federal Communications Commission (FCC), cTUVus, UKCA
Ports & interfaces
EPS power connector (8-pin): Yes
Motherboard power cable length: 60 cm
Peripheral (Molex) power cable length: 1050 mm, 900
PCI Express connector: Yes
SATA power cable length: 750 mm, 600 mm, 900, 1050 mm
Number of SATA power cables: 13
CPU power cable length: 70 cm
PCI Express power cable length: 60 cm
Motherboard power connector: 20+4 pin ATX
Cabling type: Fully-Modular
EPS power connector (4+4 pin): Yes
PCI Express power connectors (12-pin): 1
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 4
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): Yes
Other features
Screws included: Yes
Cable ties included: Yes
Logistics data
Shipping (inner) case net weight: 19.3 kg
Shipping (inner) case height: 26 cm
Shipping (inner) case width: 36.8 cm
Shipping (inner) case length: 52.8 cm
Products per shipping (inner) case: 4 pc(s)
