Technical details
Compliance certificates: RoHS
Certification: CE
Design
Product colour: Black
Base plate material: Copper
Number of heat pipes: 4
Fan connector: 4-pin
Number of fins: 51
Number of fans: 1 fan(s)
Fins material: Aluminium
Power
Power consumption (typical): 0.96 W
Rated voltage: 12 V
Thermal Design Power (TDP): 180 W
Rated current: 0.08 A
Weight & dimensions
Height: 159.4 mm
Width: 127 mm
Package depth: 115 mm
Depth: 72 mm
Package height: 190 mm
Package width: 190 mm
Weight: 620 g
Cable length: 0.22 m
Package weight: 993 g
Heat pipes diameter: 6 mm
Fan dimensions (W x D x H): 120 x 120 x 23 mm
Performance
Pulse-width modulation (PWM) support: Yes
Supported processor sockets: LGA 1150 (Socket H3), Socket AM5, LGA 2011 (Socket R), LGA 1700, LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 2066, LGA 1200 (Socket H5), Socket AM4, LGA 1155 (Socket H2)
Fan diameter: 12 cm
Rotational speed (max): 1500 RPM
Bearing type: Fluid Dynamic Bearing (FDB)
Type: Cooler
Noise level (high speed): 23.6 dB
Suitable location: Processor
Noise level (low speed): 11 dB
Packaging content
Manual: Yes
Mounting kit: Yes
Other features
Thermal grease: Yes
Heatsink dimensions (W x D x H): 127 x 47.4 x 159.4 mm
Logistics data
Harmonized System (HS) code: 84733080
Products per master (outer) case: 16 pc(s)
Master (outer) case gross weight: 17.2 kg
Master (outer) case length: 475 mm
Master (outer) case width: 400 mm
Master (outer) case height: 410 mm
Safety warning
Warnings: Do not touch the fan during operation.
