Technical details
Sustainability certificates: ENERGY STAR, ErP
Design
Fan speed: 0 - 2000 RPM
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
On/off switch: Yes
Power
Hold time: 21.09 ms
Combined power (+12V): 1000 W
Maximum input current (@220V): 6 A
Power protection features: Short circuit, Over voltage, Over power, Overheating, Surge & inrush protection (SIP), Under voltage, Over current
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Total power: 1000 W
Max output current (+3.3V): 22 A
Maximum input current (@110V): 12 A
Efficiency: 92.5%
Combined power (-12V): 3.6 W
Combined power (+3.3V): 120 W
Max output current (+12V1): 83.4 A
Max output current (+5Vsb): 3 A
Peak power: 1050 W
Power factor: 0.98
Max output current (+5V): 22 A
Combined power (+5V): 120 W
Power Factor Correction (PFC) type: Active
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Number of +12V rail(s): 1
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 86 mm
Weight: 2.64 kg
Depth: 160 mm
Width: 150 mm
Performance
Purpose: PC
Mean time between failures (MTBF): 100000 h
EPS version: 2.92
80 PLUS certification: 80 PLUS Gold
ATX version: 3.1
Bearing technology: Rifle
Power supply unit (PSU) form factor: ATX
Noise level: 30.3 dB
Packaging data
Package weight: 3.4 kg
Package width: 210 mm
Package depth: 320 mm
Package height: 133 mm
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Certificates
Compliance certificates: RoHS, CE, CCC, cTUVus, CB, IRAM, UKCA, BSMI, WEEE, RCM, Federal Communications Commission (FCC), TÜV mark
Ports & interfaces
SATA power cable length: 800, 650 mm, 950 mm, 500 mm
Cabling type: Fully-Modular
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power cable length: 800, 950 mm
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 4
CPU P4 connector (4-pin): 2
CPU power cable length: 65 cm
Motherboard power cable length: 55 cm
Peripheral (Molex) power connectors (4-pin): 2
EPS power connector (8-pin): Yes
PCI Express power connectors (12-pin): 1
Other features
Cable ties included: Yes
Screws included: Yes
Logistics data
Products per shipping (inner) case: 6 pc(s)
Shipping (inner) case length: 58 cm
Shipping (inner) case height: 23.3 cm
Shipping (inner) case gross weight: 22.7 kg
Shipping (inner) case width: 32.5 cm
