Technical details
Sustainability compliance: Yes
Compliance certificates: RoHS, CE
Design
Fan connector: 4-pin
Base plate material: Copper
Fins material: Aluminium
Number of heat pipes: 4
Number of fans: 1 fan(s)
Number of fins: 53
Product colour: Aluminium, Black, Copper
Power
Rated voltage: 12 V
Rated current: 0.11 A
Thermal Design Power (TDP): 160 W
Power consumption (typical): 1.32 W
Weight & dimensions
Fan dimensions (W x D x H): 135 x 135 x 22 mm
Depth: 74 mm
Height: 161 mm
Package height: 180 mm
Width: 137 mm
Heat pipes diameter: 6 mm
Package depth: 185 mm
Package weight: 1.1 kg
Package width: 130 mm
Weight: 690 g
Performance
Noise level (low speed): 11.5 dB
Noise level (high speed): 23.7 dB
Suitable location: Processor
Bearing type: Rifle bearing
Pulse-width modulation (PWM) support: Yes
Fan diameter: 13.5 cm
Rotational speed (max): 1400 RPM
Quantity per pack: 1 pc(s)
Mean time between failures (MTBF): 80000 h
Type: Cooler
Supported processor sockets: LGA 1155 (Socket H2), Socket AM4, LGA 2066, LGA 1700, LGA 1200 (Socket H5), LGA 1150 (Socket H3), Socket AM5, LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 2011 (Socket R)
Packaging content
Manual: Yes
Screws included: Yes
Mounting kit: Yes
Other features
Heatsink dimensions (W x D x H): 130 x 52 x 161 mm
Thermal grease: Yes
Country of origin: Germany
Logistics data
Shipping (inner) case gross weight: 19 kg
Shipping (inner) case height: 39 cm
Products per shipping (inner) case: 16 pc(s)
Shipping (inner) case length: 55 cm
Harmonized System (HS) code: 84733080
Shipping (inner) case width: 40 cm
