Technical details
Sustainability certificates: ENERGY STAR, ErP
Design
Cooling type: Active
Fan diameter: 12 cm
On/off switch: Yes
Product colour: Black
Number of fans: 1 fan(s)
Fan speed: 0 - 1800 RPM
Power
Power protection features: Over power, Overheating, Under voltage, Over current, Short circuit, Over voltage, Surge & inrush
Input current: 4 A
AC input voltage: 200 - 240 V
Total power: 550 W
Power factor: 0.98
AC input frequency: 50 Hz
Efficiency: 89.7%
Combined power (+3.3V): 120 W
Combined power (+12V): 550 W
Max output current (-12V): 0.3 A
Combined power (-12V): 3.6 W
Max output current (+12V1): 45.83 A
Max output current (+5V): 20 A
Max output current (+5Vsb): 3 A
Combined power (+5Vsb): 15 W
Combined power (+5V): 120 W
Hold time: 16.86 ms
Max output current (+3.3V): 20 A
Number of +12V rail(s): 1
Weight & dimensions
Width: 150 mm
Depth: 86 mm
Height: 140 mm
Weight: 1.92 kg
Performance
Power supply unit (PSU) form factor: ATX
Noise level: 24.2 dB
Purpose: PC
ATX version: 3.1
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
EPS version: 2.92
Bearing technology: Rifle
Packaging data
Package type: Box
Package depth: 268 mm
Package weight: 2.3 kg
Package height: 97 mm
Package width: 195 mm
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Compliance certificates: UKCA, WEEE, CB, RoHS, CE, TÜV mark
Ports & interfaces
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power connectors (4-pin): 1
Cabling type: Non-Modular
Number of SATA power connectors: 5
CPU P4 connector (4-pin): 1
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (12-pin): 1
Other features
Screws included: Yes
Cable ties included: Yes
Logistics data
Products per shipping (inner) case: 6 pc(s)
Shipping (inner) case length: 55.6 cm
Shipping (inner) case width: 31.1 cm
Shipping (inner) case height: 21.8 cm
Shipping (inner) case gross weight: 14.9 kg
