Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen 3000 Series
Processor socket: Socket AM4
Supported processor sockets: Socket AM4
Graphics
DirectX version: 12.0
HDCP: Yes
Features
Windows operating systems supported: Windows 11, Windows 10
Motherboard chipset: AMD A520
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Supported processor sockets (cooler): Socket AM4
Power source type: ATX
Memory
Supported memory clock speeds: 2933, 3600, 3200, 4266, 2400, 2133 MHz, 3800, 2667, 4400, 4133, 4000
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory module capacities: 16GB, 8GB, 32GB
Maximum internal memory: 64 GB
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Memory slots type: SO-DIMM
Supported memory clock speed (max): 4400 MHz
Weight & dimensions
Depth: 190 mm
Width: 235 mm
Network
Ethernet LAN: Yes
LAN controller: Realtek RTL8111H
Bluetooth: No
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
Front panel connector: Yes
Power fan connector: Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Audio connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
BIOS
BIOS type: UEFI
Storage controllers
Number of HDDs supported: 4
RAID levels: 0, 10, 1
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
Number of storage drives supported: 1
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Headphone outputs: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Line-in: Yes
PS/2 ports quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 slots: 1
PCI Express x1 (Gen 3.x) slots: 2
