Processor
Compatible processor series: AMD Ryzen™ 3
Processor manufacturer: AMD
Features
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard chipset: AMD A520
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Memory
Supported memory types: DDR4-SDRAM
Number of memory slots: 2
Memory slots type: DIMM
Supported memory clock speeds: 2667, 4400, 3800, 2933, 3600, 3200, 2133, 4000, 2400
Maximum internal memory: 64 GB
Weight & dimensions
Width: 235 mm
Depth: 208 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
LAN controller: Realtek RTL8111H
Internal I/O
TPM connector: Yes
CPU fan connector: Yes
Number of COM connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 (Gen 2) ports: 2
Storage controllers
RAID levels: 0, 1, 10
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Line-in: Yes
Microphone in: Yes
Headphone outputs: 1
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 1
Safety warning
Warnings: Store away from water and sources of moisture., Avoid direct contact with sensitive electronic components., Dispose of according to local electro-waste regulations.
