Processor
Maximum number of SMP processors: 1
Processor cores: 2
Processor manufacturer: AMD
Processor model: E1-6010
Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Features
PC health monitoring: CPU, Fan, Temperature
Windows operating systems supported: Windows 7, Windows 8.1, Windows 10
Component for: PC
Audio output channels: 7.1 channels
Audio chip: Realtek ALC887
Motherboard chipset family: AMD
Motherboard form factor: mini ITX
Memory
Memory voltage: 1.25 V
Supported memory types: DDR3-SDRAM, DDR3L-SDRAM
Number of memory slots: 2
Supported memory clock speeds: 800, 1333, 1066
Maximum internal memory: 16 GB
Supported memory module capacities: 8GB, 512MB, 1GB, 2GB, 4GB
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 170 mm
Depth: 170 mm
Network
Wi-Fi: No
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
Number of COM connectors: 1
Front panel audio connector: Yes
Number of SATA III connectors: 2
Front panel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
S/PDIF out connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 1
BIOS
Clear CMOS jumper: Yes
Bundled software: BullGuard
Smart Speed LAN
Packaging content
Drivers included: Yes
Cables included: SATA
Storage controllers
Supported storage drive interfaces: SATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 2
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express x16 (Gen 2.x) slots: 1
Logistics data
Harmonized System (HS) code: 84733020
