Processor
Compatible processor series: Intel® Pentium®, Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Celeron®
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Features
Audio chip: Realtek ALC897
Motherboard chipset: Intel B760
Windows operating systems supported: Yes
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Cooling type: Passive
Motherboard chipset family: Intel
Power source type: ATX
Memory
Memory slots type: DIMM
Supported memory clock speeds: 6000, 5400, 5200, 5600, 4800
Number of memory slots: 2
Supported memory types: DDR5-SDRAM
Maximum internal memory: 64 GB
Weight & dimensions
Depth: 208 mm
Width: 236 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Yes (no WiFi card included): Yes (no WiFi card included)
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
TPM connector: Yes
Number of M.2 (E) slots: 1
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 1
Front panel audio connector: Yes
Number of COM connectors: 1
Packaging content
Set contents: WiFi antenna accessories
Cables included: SATA
Drivers included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Rear panel I/O ports
Audio ports quantity: 3
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
VGA (D-Sub) ports quantity: 1
Number of Wi-Fi antenna ports: 1
DVI ports quantity: 1
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
