Processor
Processor manufacturer: Intel
Processor socket: LGA 1700
Features
Windows operating systems supported: Yes
Audio output channels: 7.1 channels
Cooling type: Passive
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Power source type: ATX
Motherboard chipset: Intel B760
Motherboard chipset family: Intel
Memory
Memory slots type: DIMM
Supported memory clock speeds: 2933, 3200 MHz, 3600, 4600, 3866, 2133, 3733, 3800, 2666, 2400, 2800, 1866
Maximum internal memory: 128 GB
Number of memory slots: 4
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
LAN controller: Intel I219V
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: Yes
Internal I/O
Number of chassis fan connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
TPM connector: Yes
Number of SATA III connectors: 8
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
USB 2.0 connectors: 3
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Number of audio jack connectors: 3
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 3
