Processor
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Pentium®
Processor socket: LGA 1700
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Graphics
DirectX version: 12.0
HDCP: Yes
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
PC health monitoring: Fan, Temperature, Voltage, CPU
Motherboard chipset: Intel H610
Motherboard chipset family: Intel
Memory
Memory slots type: DIMM
Supported memory module capacities: 32GB, 24GB, 8GB, 48GB, 16GB
Memory channels: Dual-channel
Maximum internal memory: 96 GB
Number of memory slots: 2
Supported memory types: DDR5-SDRAM
Supported memory clock speeds: 4800
Weight & dimensions
Width: 208 mm
Depth: 236 mm
Network
LAN controller: Intel® I219-V
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of SATA III connectors: 4
Front panel connector: Yes
Number of COM connectors: 1
Front panel audio connector: Yes
USB 2.0 connectors: 2
Power fan connector: Yes
ATX Power connector (24-pin): Yes
BIOS
BIOS type: UEFI
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI ports quantity: 1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) ports quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Logistics data
Harmonized System (HS) code: 84733020
