Processor
Compatible processor series: Intel Core i5 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i7 13th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
DirectX version: 12.0
On-board graphics card: Yes
HDCP: Yes
Features
Audio chip: Realtek ALC897
Product colour: Black
Motherboard chipset: Intel H610
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
PC health monitoring: Voltage, Fan, Temperature
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: Intel
Memory
Supported memory clock speeds: 2133, 1866, 2400, 2933, 3200 MHz, 2666
Maximum internal memory: 64 GB
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 185 mm
Depth: 226 mm
Network
LAN controller: Realtek RTL8111H
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 1
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Front panel connector: Yes
CPU fan connector: Yes
Number of EPS power connectors (8-pin): 1
USB 2.0 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Drivers included: Yes
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 2.0 ports quantity: 4
HDMI version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
VGA (D-Sub) ports quantity: 1
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
