Processor
Compatible processor series: Intel Core i5 12th Gen, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 13th Gen, Intel Core i9 13th Gen, Intel Core i3 12th Gen, Intel Core i7 12th Gen, Intel Core i9 14th Gen, Intel® Celeron®
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
Features
Motherboard chipset: Intel H610
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Memory
Supported memory clock speeds: 3200, 2666, 2133 MHz, 2400, 1866, 2933
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Maximum internal memory: 64 GB
Memory slots type: DIMM
Number of memory slots: 2
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 216 mm
Depth: 228 mm
Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
Number of SATA III connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of COM connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Drivers included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
DisplayPorts quantity: 1
Microphone in: Yes
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
