Processor
Compatible processor series: Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3
Processor manufacturer: Intel
Processor socket: LGA 1200 (Socket H5)
Graphics
HDCP: Yes
Features
Motherboard form factor: ATX
Motherboard chipset: Intel Z590
Audio output channels: 7.1 channels
Audio chip: Realtek ALC887
Product colour: Black
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Supported memory clock speeds: 3200 MHz, 2666, 2400, 2800, 2933, 3600, 2133
Maximum internal memory: 128 GB
Supported memory clock speed (max): 3600 MHz
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
ECC сompatibility: Non-ECC
Number of memory slots: 4
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
LAN controller: Intel I219V
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Mobile network connection: No
Internal I/O
USB 2.0 connectors: 2
Number of COM connectors: 1
Number of SATA III connectors: 10
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
Front panel connector: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 14
Number of HDDs supported: 10
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 4
PCI Express x1 (Gen 3.x) slots: 8
Safety warning
Warnings: Avoid contact with liquids to prevent damage to electronic components., Do not make changes or modifications to the appliance, which may void the warranty or cause damage., Be careful when assembling to avoid damage to electronic components caused by electrostatic discharge.
