Processor
Compatible processor series: Intel Core i9 13th Gen, Intel Core i3 14th Gen, Intel Core i7 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 13th Gen, Intel Core i3 12th Gen, Intel Core i9 14th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel Z690
PC health monitoring: Fan, CPU, Temperature
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Memory
Number of memory slots: 2
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
ECC сompatibility: Non-ECC
Memory slots type: DIMM
Supported memory clock speeds: 4000, 3800, 3200, 2666, 1866, 2933, 3600, 4400, 2133 MHz, 2400
Maximum internal memory: 64 GB
Weight & dimensions
Depth: 236 mm
Width: 208 mm
Network
Ethernet LAN: Yes
LAN controller: Realtek RTL8125B
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
TPM connector: Yes
USB 2.0 connectors: 4
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Number of chassis fan connectors: 1
BIOS
BIOS type: UEFI
Bundled software: BullGuard
Packaging content
Drivers included: Yes
Cables included: SATA
Storage controllers
RAID support: Yes
RAID levels: 10, 5, 1, 0
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 5
Supported storage drive types: HDD & SSD
Rear panel I/O ports
DVI-D ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
