Features Response time: 0 ms Power source type: AC Number of input phases: 1 Input operation voltage (max): 280 V Waveform: Pure sine Output voltage Total Harmonic Distortion (THD): 3% Input operation voltage (min): 110 V Output power factor: 1 Output frequency regulation: 0.1 Hz Output power: 5000 W Efficiency (On-line mode): 93% Output power capacity: 5 kVA Emergency Power Off (EPO): Yes Output voltage regulation: 3% UPS topology: Double-conversion (Online) ECO mode: Yes Input frequency: 45/66 Hz Number of output phases: 1
Design Product colour: Black LED indicators: Yes Form factor: Tower Display type: LCD Built-in fan: Yes Cooling type: Active Control type: Buttons International Protection (IP) code: IP20
Operational conditions Operating temperature (T-T): 0 - 50 °C Operating relative humidity (H-H): 5 - 95%
Weight & dimensions Weight: 14.2 kg Width: 465 mm Height: 190 mm Depth: 336 mm Bundled software: ViewPower
Packaging data Package weight: 15.7 kg Package width: 560 mm Package height: 460 mm Package depth: 330 mm
Packaging content Batteries included: No
Ports & interfaces Power plug: Terminal SmartSlot: Yes USB port type: USB Type-B USB port: Yes AC outlet types: Terminal
Battery Battery voltage: 48 V Charging current: 60 A Cold start: Yes Battery technology: Sealed Lead Acid (VRLA)
