Technical details
Pallet type: 800 x 1200 mm
Design
Built-in display: No
Scanner type: ADF scanner
Product colour: Black, White
Control type: Buttons
Power
Power consumption (standby): 5.4 W
Power consumption (typical): 23 W
Power consumption (off): 0.1 W
Power supply type: AC
Power consumption (sleep): 1.4 W
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Height: 391 mm
Depth: 320 mm
Weight: 3.02 kg
Width: 243 mm
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2019, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Performance
Scan drivers: SANE, WIA, ICA
Scan to: USB, PC, Image
Scanning noise level: 59 dB
Sensor type: Dual CIS
Packaging data
Package height: 243 mm
Package weight: 3.7 kg
Package width: 391 mm
Package depth: 320 mm
Packaging content
Cables included: AC, USB
Ports & interfaces
USB port: Yes
USB version: 2.0
Other features
Spare part retention: 5 year(s)
Logistics data
Country of origin: China
Products per pallet: 50 pc(s)
Master (outer) cases per pallet: 50 pc(s)
Layers per pallet: 5 pc(s)
Pallet gross height: 17.7 cm
Master (outer) cases per pallet layer: 10 pc(s)
Harmonized System (HS) code: 84716070
Pallet gross weight: 202 kg
Input capacity
Auto document feeder (ADF) input capacity: 60 sheets
Paper handling
Auto Document Feeder (ADF) media weight: 40 - 200 g/m²
Scanning media types supported: Plastic Card, Recycled paper, Thin paper, Plain paper, Business Card, Thick paper
Maximum ISO A-series paper size: A4
Maximum scan length: 35.5 cm
Maximum scan width: 21.6 cm
Card thickness (max): 1.1 mm
Scanning
Enhanced scan resolution: 1200 x 1200 DPI
Optical scanning resolution: 600 x 600 DPI
Duplex scanning: Yes
Duplex ADF scan speed (b/w, A4): 70 ipm
Colour scanning: Yes
Maximum scan size: 215.9 x 355.6 mm
ADF scan speed (b/w, A4): 35 ppm
Greyscale levels: 256
ADF scan speed (colour, A4): 35 ppm
Duplex ADF scan speed (colour, A4): 70 ipm
