Technical details
Pallet type: 800 x 1200 mm
Design
Display: LCD
Product colour: White, Black
Display diagonal: 10.9 cm (4.3")
Built-in display: Yes
Control type: Touch
Touchscreen: Yes
Colour display: Yes
Scanner type: ADF + Sheet-fed scanner
Power
Power consumption (typical): 34 W
Power consumption (off): 0.1 W
Output voltage: 24 V
Power consumption (standby): 7.7 W
Output current: 1.9 A
Auto power off: Yes
Power consumption (sleep): 1.7 W
Power supply type: AC
Sleep mode: Yes
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 3.81 kg
Height: 393 mm
Width: 288 mm
Depth: 334 mm
Network
Security algorithms: SNMPv3, SSL/TLS, EAP-TTLS, WPA2-AES, EAP-TLS, SMTP-AUTH, TKIP, EAP-MD5, WPA-PSK, WPA3, AES, HTTPS, WEP, PEAP, TLS, WPA2-PSK, EAP-FAST
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, 802.11a, 802.11g
IPv6 support: Yes
Wi-Fi: Yes
Ethernet LAN: Yes
Supported network protocols (IPv6): RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6
System requirements
Mac operating systems supported: Yes
Windows operating systems supported: Yes
Server operating systems supported: Windows Server 2019, Windows Server 2012 R2, Windows Server 2016
Linux operating systems supported: Yes
Performance
Scan drivers: WIA, ISIS, TWAIN, SANE
Scanning noise level: 62 dB
Maximum duty cycle: 180000 pages per month
Scan to: E-mail Server, SMB, FTP, HTTP, PC
Daily duty cycle (max): 9000 pages
Scan file formats: PDF, JPEG, TIFF
Ultrasonic sensor: Yes
Sensor type: Dual CIS
Light source: LED
Packaging data
Package weight: 4.6 kg
Package width: 393 mm
Package height: 334 mm
Package depth: 288 mm
Packaging content
Cables included: AC, USB
Ports & interfaces
USB port: Yes
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Certification: GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0
Other features
Cable lock slot: Yes
Spare part retention: 5 year(s)
Logistics data
Master (outer) cases per pallet: 40 pc(s)
Layers per pallet: 5 pc(s)
Harmonized System (HS) code: 84716070
Master (outer) cases per pallet layer: 8 pc(s)
Pallet gross weight: 186 kg
Input capacity
Auto document feeder (ADF) input capacity: 100 sheets
Paper handling
Maximum ISO A-series paper size: A4
Scanning media types supported: Thin paper, Thick paper, Plastic Card, Recycled paper, Plain paper, Business Card
Auto Document Feeder (ADF) media weight: 25 - 413 g/m²
Long-paper mode: Yes
Maximum scan width: 21.6 cm
Card thickness (max): 1.32 mm
Paper tray media weight: 25 - 413 g/m²
Maximum scan length: 5 m
Media thickness (min): 0.08 mm
Scanning
Output colour depth: 24 bit
Duplex scanning: Yes
Output greyscale depth: 8 bit
Duplex ADF scan speed (colour, A4): 120 ipm
Input colour depth: 48 bit
Enhanced scan resolution: 1200 x 1200 DPI
Optical scanning resolution: 600 x 600 DPI
Maximum scan size: 215.9 x 355.6 mm
ADF scan speed (b/w, A4): 60 ppm
ADF scan speed (colour, A4): 60 ppm
Greyscale levels: 256
Duplex ADF scan speed (b/w, A4): 120 ipm
Colour scanning: Yes
