Technical details
Master (outer) cases per pallet layer: 4 pc(s)
Pallet type: 1200 x 1000 mm
Features
Country of origin: Vietnam
Duplex functions: Print, Copy
Printing colours: Black, Cyan, Magenta, Yellow
Number of print cartridges: 4
Recommended duty cycle: 300 - 3000 pages per month
Page description languages: PCL 6, BR-Script 3
Printer fonts: Barcode, Bitmap, PostScript, PCL
Design
Product colour: Grey
Market positioning: Home & office
Built-in display: Yes
Control type: Buttons
Display: LCD
Power
Power consumption (max): 460 W
Power consumption (off): 0.04 W
Power consumption (average operating): 310 W
Power consumption (ready): 70 W
Power consumption (printing): 310 W
Power consumption (sleep): 10 W
Energy Star Typical Electricity Consumption (TEC): 0.29 kWh/week
Power consumption (copying): 460 W
Weight & dimensions
Height: 497 mm
Depth: 497 mm
Weight: 18.8 kg
Width: 536 mm
Network
Security algorithms: 64-bit WEP, WPA2-AES, WPA-AES, WPA-PSK, 128-bit WEP, WPA-TKIP, WPA2-TKIP, WPA2-PSK
Wi-Fi: Yes
Ethernet LAN: No
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b
Mobile printing technologies: Brother iPrint & Scan, Google Cloud Print, Mopria Print Service, Apple AirPrint
Wi-Fi Direct: Yes
System requirements
Server operating systems supported: Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Mac operating systems supported: Mac OS X 10.13 High Sierra, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Windows operating systems supported: Windows 10 Home, Windows 7 Starter x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 8.1 Enterprise, Windows 7 Professional, Windows 7, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 8, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Professional x64, Windows 8 x64, Windows 10 Education, Windows 8.1, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Education x64
Linux operating systems supported: Yes
Performance
Card reader integrated: No
Processor frequency: 800 MHz
Internal memory: 512 MB
Sound pressure level (printing): 46 dB
Built-in processor: Yes
Sound pressure level (quiet mode): 43 dB
Sound power level (printing): 62 dB
Packaging data
Package width: 497 mm
Package depth: 536 mm
Package height: 497 mm
Package weight: 21.8 kg
Packaging content
User guide: Yes
Power cord included: Yes
Cables included: AC
Warranty card: Yes
Quick installation guide: Yes
Cartridge(s) included: Yes
Manual: Yes
Ports & interfaces
USB port: Yes
Standard interfaces: USB 2.0, Wireless LAN
Other features
Fonts included: Y
Printer management: Web Based Management, BRAdmin Professional for Windows, BRAdmin Light for Windows
Emulations: PCL5e, PCL5c, PCL6 (PCL XL Class 3.0), BR-Script3, PDF Version 1.7, XPS Version 1.0
Software CD: Yes
Printing
N-up printing: 4, 16, 25, 2, 9
Print speed (colour, normal quality, A4/US Letter): 18 ppm
N-in-1 print function: Yes
Duplex print speed (black, normal quality, A4/US Letter): 7 ppm
Print technology: LED
Print speed (black, normal quality, A4/US Letter): 18 ppm
Secure printing: Yes
Duplex printing: Yes
Time to first page (black, normal): 15 s
Maximum resolution: 2400 x 600 DPI
Duplex printing mode: Auto
Printing: Colour printing
Warm-up time: 28 s
Time to first page (colour, normal): 15 s
Copying
Maximum copy resolution: 600 x 600 DPI
Copy speed (colour, normal quality, A4): 18 cpm
Copying: Colour copying
Copy speed (black, normal quality, A4): 18 cpm
Copier resize: 25 - 400%
Duplex copying: Yes
Logistics data
Pallet gross weight: 279.6 kg
Products per pallet: 12 pc(s)
Master (outer) cases per pallet: 12 pc(s)
Pallet gross height: 16.5 cm
Layers per pallet: 3 pc(s)
Fax
Faxing: No
Input & output capacity
Paper input type: Paper tray
Total output capacity: 150 sheets
Total input capacity: 250 sheets
Paper tray 1 input capacity: 250 sheets
Paper handling
Paper tray media types: Plain paper, Glossy paper, Labels, Envelopes, Thin paper, Recycled paper, Thick paper
Multi-purpose tray media types: Plain paper, Thin paper, Recycled paper
Custom media width: 76.2 - 216 mm
Non-ISO print media sizes: Folio, Executive, Legal
Custom media length: 116 - 355.6 mm
Paper tray media weight: 60 - 163 g/m²
ISO A-series sizes (A0...A9): A6, A4, A5
Maximum ISO A-series paper size: A4
Scanning
Scan drivers: TWAIN, WIA, SANE
Greyscale levels: 256
Scanner type: Flatbed scanner
Scanning: Colour scanning
Scan to: OCR, FTP, Image, SMB, File, E-mail
Scan technology: CIS
Optical scanning resolution: 1200 x 1200 DPI
Safety warning
Warnings: Do not cover the ventilation openings during operation., Connect the appliance to a grounded electrical outlet.
Sustainability
Sustainability certificates: ENERGY STAR, Blue Angel
Sustainability compliance: Yes
