Technical details
Pallet type: 800 x 1200 mm
Design
Built-in display: No
Product colour: White, Black
Scanner type: Sheet-fed scanner
Power
Power consumption (typical): 2.9 W
Power consumption (off): 0.01 W
Power supply type: USB
Power consumption (standby): 1.4 W
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Height: 377 mm
Depth: 76 mm
Weight: 537 g
Width: 162 mm
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Performance
Scan drivers: ICA, TWAIN, SANE, WIA
Scan to: Image, E-mail, OCR, File
Internal memory: 256 MB
Scanning noise level: 53 dB
Sound pressure level (max): 42 dB
Packaging data
Quantity per pack: 1 pc(s)
Package weight: 1.17 kg
Package width: 377 mm
Package height: 76 mm
Package depth: 162 mm
Packaging content
Quick start guide: Yes
Cables included: Micro-USB
Warranty card: Yes
Ports & interfaces
USB connector type: Micro-USB B
USB version: 3.2 Gen 1 (3.1 Gen 1)
Standard interfaces: USB 3.2 Gen 1 (3.1 Gen 1)
USB port: Yes
Logistics data
Country of origin: China
Pallet gross weight: 286 kg
Master (outer) cases per pallet layer: 10 pc(s)
Harmonized System (HS) code: 84716070
Products per pallet: 240 pc(s)
Layers per pallet: 8 pc(s)
Master (outer) cases per pallet: 80 pc(s)
Pallet gross height: 16.7 cm
Input capacity
Standard input capacity: 1 sheets
Paper handling
Scanning media types supported: Plain paper, Plastic Card, Business Card
Maximum scan length: 182.9 cm
Maximum scan width: 21.6 cm
Maximum ISO A-series paper size: A4
Card thickness (max): 1.24 mm
Scanning
Optical scanning resolution: 600 x 600 DPI
Maximum scan size: 215.9 x 1828.8 mm
Output colour depth: 24 bit
Duplex scanning: Yes
Colour scanning: Yes
Enhanced scan resolution: 1200 x 1200 DPI
Greyscale levels: 256
Input colour depth: 48 bit
Black/white scanning colour modes: Monochrome, Grayscale
