Technical details
Master (outer) cases per pallet layer: 2 pc(s)
Pallet type: 800 x 1200 mm
Features
Country of origin: China
Page description languages: PCL 6, PDF 1.7, XPS, PostScript 3
Number of print cartridges: 1
Maximum duty cycle: 60000 pages per month
Printing colours: Yellow, Black, Magenta, Cyan
Certification: Cerner Certified, Citrix Ready
Design
Product colour: Grey
Display: LCD
Display diagonal: 6.86 cm (2.7")
Built-in display: Yes
Control type: Touch
Colour display: Yes
Market positioning: Business
Touchscreen: Yes
Power
AC input voltage: 120 V
AC input frequency: 50 - 60 Hz
Power consumption (PowerSave): 340 W
Power consumption (off): 0.03 W
Power consumption (printing): 580 W
Power consumption (ready): 1.5 W
Energy Star Typical Electricity Consumption (TEC): 0.578 kWh/week
Power consumption (standby): 70 W
Operational conditions
Operating temperature (T-T): 10 - 32 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): 0 - 40 °C
Weight & dimensions
Weight: 22.6 kg
Width: 565 mm
Height: 620 mm
Depth: 520 mm
Network
Security algorithms: SMTP-AUTH, 128-bit WEP, WPA-TKIP, SNMP, WPA2-TKIP, 64-bit WEP, WPA2-AES, EAP-MD5, IPPS, HTTPS, 802.1x RADIUS, WPA2-PSK, EAP-FAST, WPA-AES, SSL/TLS, EAP-TTLS, PEAP, WPA-PSK, IPSec, EAP-TLS
Ethernet LAN data rates: 10,100,1000 Mbit/s
Web-based management: Yes
Near Field Communication (NFC): Yes
Mobile printing technologies: Kindle Fire Printing, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service, Apple AirPrint
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b
Network ready: Yes
Wi-Fi: Yes
Ethernet LAN: Yes
System requirements
Windows operating systems supported: Yes
Performance
Processor frequency: 800 MHz
Coprocessor: Yes
Coprocessor frequency: 0.133 GHz
Sound pressure level (printing): 49 dB
Memory slots: 1
Internal memory: 512 MB
Card reader integrated: Yes
Built-in processor: Yes
Maximum internal memory: 512 MB
Packaging data
Package weight: 26.1 kg
Packaging content
Drivers included: Yes
Cables included: AC
Quick start guide: Yes
Ports & interfaces
USB 2.0 ports quantity: 1
USB port: Yes
Standard interfaces: Ethernet, Wireless LAN, USB 2.0
Direct printing: Yes
Other features
Printer management: BRAdmin Professional 3, BRAdmin Light
Spare part retention: 5 year(s)
Printing
Duplex print speed (black, normal quality, A4/US Letter): 14 ppm
N-up printing: 2, 25, 16, 4, 9
Warm-up time (from sleep mode): 29 s
Secure printing: Yes
Warm-up time: 29 s
Print technology: Laser
Print speed (black, normal quality, A4/US Letter): 31 ppm
Maximum resolution: 2400 x 600 DPI
Time to first page (colour, normal): 15 s
Duplex printing mode: Auto
Economical printing: Yes
Duplex printing: Yes
Colour: Yes
Time to first page (black, normal): 15 s
Print speed (colour, normal quality, A4/US Letter): 31 ppm
Logistics data
Pallet gross height: 16.9 cm
Master (outer) cases per pallet: 6 pc(s)
Layers per pallet: 3 pc(s)
Harmonized System (HS) code: 84433210
Products per pallet: 6 pc(s)
Pallet gross weight: 173.4 kg
Input & output capacity
Maximum number of input trays: 4
Total output capacity: 150 sheets
Total input capacity: 250 sheets
Multi-Purpose tray: Yes
Total number of input trays: 1
Paper input type: Paper tray, Cassette
Auto document feeder (ADF) input capacity: 50 sheets
Paper handling
Paper tray media types: Thin paper, Recycled paper, Plain paper
Duplex media weight: 60 - 105 g/m²
Paper tray media weight: 60 - 105 g/m²
Maximum ISO A-series paper size: A4
Multi-purpose tray media types: Labels, Thin paper, Envelopes, Recycled paper, Thicker paper, Plain paper, Thick paper, Glossy paper
Custom media length: 127 - 355.6 mm
Auto Document Feeder (ADF) media weight: 60 - 163 g/m²
Custom media width: 76.2 - 215.9 mm
ISO A-series sizes (A0...A9): A4, A5, A6
Non-ISO print media sizes: Folio, Letter, Executive, Legal
Envelopes sizes: Com-10, DL, C5
Safety warning
Warnings: Do not cover the ventilation openings during operation., Connect the appliance to a grounded electrical outlet., Avoid contact with liquids and moisture.
Sustainability
Sustainability certificates: Blue Angel, ENERGY STAR
