Technical details
Master (outer) cases per pallet layer: 2 pc(s)
Pallet type: 800 x 1200 mm
Replacement cartridges: TN-910BK
TN-910C
TN-910M
TN-910Y
Features
Maximum duty cycle: 80000 pages per month
Number of print cartridges: 4
Linear (1D) barcodes supported: GS1 DataBar, Code 128A, UPC-A, Code 93, POSTNET, Code 39, UPC-E, ISBN, MSI, Interleaved 2 of 5, Facing Identification Mark, Code 128C, Codabar, Code 128B
Page description languages: PCL 6, XPS, BR-Script 3, PDF 1.7
Design
Display diagonal: 6.86 cm (2.7")
Built-in display: Yes
Display: LCD
Market positioning: Business
Colour display: Yes
Control type: Touch
Power
Power consumption (printing): 580 W
Power consumption (ready): 70 W
Energy Star Typical Electricity Consumption (TEC): 1.8 kWh/week
Weight & dimensions
Width: 605 mm
Weight: 23 kg
Height: 645 mm
Depth: 575 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b
Wi-Fi: Yes
Security algorithms: SMTP-AUTH, IPSec, WPS, PEAP, AES, 802.1x RADIUS, EAP-FAST, EAP-TLS, WPA-PSK, 128-bit WEP, TKIP, LEAP, 64-bit WEP, SNMPv3, SSL/TLS, EAP-TTLS
Ethernet LAN: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Mobile printing technologies: Apple AirPrint, Mopria Print Service, Brother iPrint & Scan, Google Cloud Print
Network ready: Yes
Near Field Communication (NFC): Yes
System requirements
Mac operating systems supported: Yes
Windows operating systems supported: Windows 7, Windows 8, Windows 10
Server operating systems supported: Windows Server 2012, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016
Linux operating systems supported: Yes
Performance
Internal memory: 1024 MB
Processor frequency: 800 MHz
Sound pressure level (quiet mode): 44 dB
Sound pressure level (printing): 49 dB
Sound power level (standby): 60 dB
Sound power level (printing): 65.5 dB
Built-in processor: Yes
Packaging data
Package height: 578 mm
Package depth: 603 mm
Package width: 642 mm
Package weight: 27 kg
Packaging content
Cartridge(s) included: Yes
Included cartridge capacity (black): 6500 pages
Ports & interfaces
Direct printing: Yes
USB 2.0 ports quantity: 3
USB port: Yes
USB connector: USB Type-A
Other features
Online services supported: Google Drive, Dropbox
Dimensions (W x D x H) (imperial): 442 x 485.1 x 312.4 mm (17.4 x 19.1 x 12.3")
Authentication method: LDAP, ActiveDirectory, RADIUS
Spare part retention: 5 year(s)
Printing
Print technology: Laser
Time to first page (colour, normal): 15 s
Colour: Yes
Duplex print speed (black, normal quality, A4/US Letter): 14 ppm
Time to first page (black, normal): 15 s
N-up printing: 2, 9, 4, 25, 16
Duplex print speed (colour, normal quality, A4/US Letter): 14 ppm
Booklet printing function: Yes
Maximum resolution: 2400 x 600 DPI
Duplex printing mode: Auto/Manual
Print speed (black, normal quality, A4/US Letter): 31 ppm
Watermark printing: Yes
Duplex printing: Yes
Print speed (colour, normal quality, A4/US Letter): 31 ppm
Warm-up time: 29 s
Logistics data
Layers per pallet: 3 pc(s)
Pallet gross weight: 178.8 kg
Master (outer) cases per pallet: 6 pc(s)
Input & output capacity
Multi-Purpose tray input capacity: 50 sheets
Maximum output capacity: 150 sheets
Maximum input capacity: 2380 sheets
Total output capacity: 150 sheets
Total input capacity: 300 sheets
Paper tray 1 input capacity: 250 sheets
Multi-Purpose tray: Yes
Total number of input trays: 1
Paper handling
Custom media length: 127 - 355.6 mm
Custom media width: 76.2 - 215.9 mm
Multi-purpose tray media types: Plain paper, Letterhead, Recycled paper, Bond paper, Glossy paper
ISO A-series sizes (A0...A9): A6, A5, A4
Paper tray media types: Plain paper, Letterhead, Labels, Recycled paper, Envelopes, Glossy paper, Bond paper
Multi-Purpose Tray media weight (imperial): 7.26 - 19.5 kg (16 - 43 lbs)
Non-ISO print media sizes: Letter, Executive, Legal
Paper tray media weight (imperial): 7.26 - 12.7 kg (16 - 28 lbs)
Envelopes sizes: 10
Maximum ISO A-series paper size: A4
Paper tray media weight: 60 - 105 g/m²
Safety warning
Warnings: Connect the appliance to a grounded electrical outlet., Avoid contact with liquids and moisture., Do not cover the ventilation openings during operation.
Sustainability
Sustainability compliance: Yes
Sustainability certificates: Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
