Design
Display: LED
Display diagonal: 10.9 cm (4.3")
On Screen Display (OSD) languages: French, English, Spanish, Polish, German, Italian
Product colour: Black
Control type: Buttons
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 25 - 85%
Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
Depth: 510 mm
Width: 357 mm
Height: 313 mm
Weight: 17.9 kg
System requirements
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Windows operating systems supported: Windows 10, Windows 11
Mobile operating systems supported: iOS 16, Android 13.0, iOS 12
Server operating systems supported: SUSE Linux Enterprise Server 12
Performance
Built-in barcodes: ITF-14, Plessey, MSI, UPC 2(5), AZTECCODE, PDF417, GS1 DataBar, MicroPDF417, Planet, Deutsche Post Leitcode, TELEPENN, Code-128 Codabar Library, China post, GS1 DataMatrix, EAN8, MaxiCode, Interleaved 2/5, TLC39, TELEPEN, Standard 2/5, Deutsche Post Identcode, Code 128 (A/B/C), QR Code, LOGMARS, Industrial 2/5, Code 49, Code 39, EAN128, EAN14, POSTNET, Codablock F, EAN13, Code 11, Code128UCC
Flash memory: 512 MB
Page description languages: EPL2, DPL
Internal memory: 256 MB
Bundled software: BarTender Ultra Lite Edition: Barcode label design software
Packaging content
Cables included: AC, USB
Ports & interfaces
Wi-Fi: Yes
Connectivity technology: Wired
USB port: Yes
Ethernet LAN: Yes
Bluetooth version: 4.2
Bluetooth: Yes
Wi-Fi standards: 802.11a, Wi-Fi 4 (802.11n), 802.11b, 802.11g
USB 2.0 ports quantity: 1
RS-232 ports: 1
Other features
Warranty period: 5 year(s)
Printing
Minimum print length: 14.7 m
Print technology: Direct thermal / Thermal transfer
Print speed: 304.8 mm/sec, 10 lpm
Maximum printing width: 17.3 cm
Maximum resolution: 203 x 300 DPI
Colour: Yes
Paper handling
Ribbon width: 17.8 cm
Autocutter: Yes
Ribbon length: 450 m
Maximum roll diameter: 20.8 cm
Core diameters supported: 38.1 mm (1.5")
