Technical details
Pallet type: 800 x 1200 mm
Design
Product colour: White, Black
Built-in display: No
Power
AC input frequency: 60 Hz
AC adapter output current: 1.7 A
AC input voltage: 120 V
Weight & dimensions
Height: 183 mm
Weight: 1.47 kg
Width: 262 mm
Depth: 239 mm
System requirements
Mac compatibility: Yes
Performance
Built-in barcodes: CODABAR (NW-7), PDF417, UPC-E, POSTNET, UPC-A, EAN13, EAN8, Interleaved 2/5, EAN128
Tape cutting: Automatic
Tape type: DK
Packaging data
Package weight: 2.13 kg
Package dimensions (WxDxH): 182 x 262 x 233 mm
Package width: 260.4 mm
Package height: 234.9 mm
Quantity per pack: 1 pc(s)
Package depth: 184.2 mm
Ports & interfaces
Wi-Fi: No
Ethernet LAN: No
PC connected: Yes
Other features
Country of origin: China
Network ready: No
Dimensions (WxDxH): 128 x 221 x 153 mm
Spare part retention: 5 year(s)
Number of label formats: 22
Quantity outer carton: 3 pc(s)
Printing
Maximum printing width: 6.2 cm
Maximum resolution: 300 x 300 DPI
Print technology: Direct thermal
Maximum print height: 5.9 cm
Print speed: 150 mm/sec
Rotated printing: Yes
Vertical printing: Yes
Logistics data
Products per pallet: 108 pc(s)
Harmonized System (HS) code: 84433210
Master (outer) cases per pallet: 36 pc(s)
Layers per pallet: 6 pc(s)
Pallet gross weight: 255.6 kg
Pallet gross height: 16.5 cm
Master (outer) cases per pallet layer: 6 pc(s)
Master (outer) case length: 555 mm
Master (outer) case width: 274 mm
Paper handling
Maximum label length: 1 m
Maximum label width: 6.2 cm
