Technical details
Pallet type: 800 x 1200 mm
Master (outer) cases per pallet layer: 8 pc(s)
Features
Country of origin: China
RAM capacity: 0.256 GB
Flash memory: 64 MB
Design
Display: LCD
Built-in display: Yes
Product colour: Black
Power
AC input voltage: 110/220 V
AC input frequency: 50 - 60 Hz
Power source type: Battery, DC
Battery technology: Lithium-Ion (Li-Ion)
Battery recharge time: 4 h
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -20 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 700 g
Width: 121 mm
Height: 187 mm
Depth: 247 mm
Network
Wi-Fi: No
Ethernet LAN: No
System requirements
Windows operating systems supported: Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 8 x64, Windows 10 Education, Windows 10 Enterprise x64, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 8.1, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 10 Pro x64, Windows 8 Enterprise, Windows 7 Professional x64, Windows 10 Home, Windows 7 Starter x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 10 Home x64, Windows 8, Windows 7 Professional, Windows 7, Windows 7 Home Basic, Windows 7 Ultimate, Windows 10 Education x64
Packaging data
Package weight: 1.28 kg
Packaging content
Batteries included: Yes
Ports & interfaces
Connectivity technology: Wired & Wireless
Bluetooth: Yes
USB 2.0 ports quantity: 1
Standard interfaces: NFC, Bluetooth, USB 2.0
Bluetooth version: 4.2
USB connector: Mini-USB Type-B
Bluetooth profiles: GATT, OPP, SPP, HCRP
USB port: Yes
Near Field Communication (NFC): Yes
Other features
International Protection (IP) code: IP54
Rechargeable: Yes
Printing
Type: Mobile printer
Maximum resolution: 203 x 203 DPI
Print technology: Direct thermal
Print speed: 5 ips, 127 mm/sec
Logistics data
Pallet gross weight: 244.2 kg
Master (outer) cases per pallet: 56 pc(s)
Products per pallet: 168 pc(s)
Harmonized System (HS) code: 84433210
Pallet gross height: 16.6 cm
Layers per pallet: 7 pc(s)
Paper handling
Maximum media length: 3 m
Maximum roll diameter: 5.8 cm
Maximum printing width: 10.4 cm
Supported paper width: 45 - 113 mm
