Technical details
Pallet type: 800 x 1200 mm
Design
Built-in display: No
Product colour: Grey, Black
Control type: Buttons
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power source type: AC, USB
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 5 - 40 °C
Weight & dimensions
Depth: 224 mm
Weight: 1.59 kg
Width: 119 mm
Height: 158 mm
System requirements
Windows operating systems supported: Windows 10, Windows 11
Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2022, Windows Server 2019, Windows Server 2016
Performance
Built-in barcodes: EAN13, Data Matrix, AZTECCODE, UPC-A, MSI, EAN8, MaxiCode, Code 128 (A/B/C), Code 39, Micro QR Code, Code 93, QR Code, POSTNET, CODABAR (NW-7), UPC-E, GS1 DataBar
Internal memory: 256 MB
Flash memory: 64 MB
Packaging data
Package height: 325 mm
Package width: 306 mm
Package depth: 181 mm
Package weight: 2.63 kg
Packaging content
Cables included: AC, USB
Ports & interfaces
Wi-Fi: No
Ethernet LAN: Yes
Connectivity technology: Wired
USB port: Yes
RS-232 ports: 1
Other features
Warranty period: 3 year(s)
Spare part retention: 5 year(s)
Country of origin: Vietnam
Printing
Print technology: Direct thermal
Maximum printing width: 5.9 cm
Maximum resolution: 203 x 203 DPI
Minimum print length: 6.4 mm
Print speed: 152 mm/sec
Colour: No
Logistics data
Layers per pallet: 5 pc(s)
Products per pallet: 60 pc(s)
Pallet gross height: 17.8 cm
Master (outer) cases per pallet: 20 pc(s)
Pallet gross weight: 631.2 kg
Master (outer) cases per pallet layer: 4 pc(s)
Paper handling
Maximum roll diameter: 12.7 cm
Core diameter: 3.81 cm
Maximum label length: 3 m
Media thickness: 0.058 - 0.279 mm
